STEP 11
1. Secure part 12 to the top of part 18 using:
- 4x part 73
- 8x part 85
- 4x part 83
18 | ASSEMBLY INSTRUCTIONS
M10 x 75mm 4pcs
M10 x 15mm 4pcs
83
85
85
83
79
79
85
79
79
85
85
36
35
12
73
2. Secure part 35 and 36 onto part 12 using:
- 4x part 79
- 8x part 85
Φ 10
12pcs
M10 4pcs
83
85
73
