Cortex Multi Gym SM25 User Manual page 16

74
85
83
74
74
85
STEP 9
1. Secure 2x part 18 onto part 11 using:
- 3x part 74 - 6x part 85
2. Repeat step 1 for the other side.
16 | ASSEMBLY INSTRUCTIONS
M10 x 70mm 8pcs
Φ 10
16pcs
M10 8pcs
74
85
17
- 3x part 83
85
83
83
18
11
18
83
85
17
3. Secure 2x part 17 onto part 11 and part 1 using:
- 1x part 74
4. Repeat step 2 for the other side.
- 2x part 85 - 1x part 83
