Chapter 3: BIOS Setup
BIOS Setup Utility
Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on
the screen. The main menu allows you to select from several setup functions
and one exit. Use arrow keys to select among the items and press
accept or enter the submenu.
Main
The Main menu is the first screen that you will see when you enter the BIOS
Setup Utility.
Aptio Setup Utility - Copyright (C) 2021 American Megatrends, Inc.
Main
Advanced
Chipset
Security
BIOS Information
BIOS Vendor
American Megatrends
Core Version
5.12
Compliancy
UEFI 2.5; PI 1.4
Project Version
X101-005
Build Date and Time
06/22/2021 16:55:12
Access Level
Administrator
Platform firmware Information
BXT SOC
F1
TXE FW
3.0.13.1144
GOP
10.0.1036
Memory Information
Total Memory
8192 MB
Memory Speed
1866 MHz
System Date
[Thu 06/10/2021]
System Time
[01:12:00]
Version 2.18.1263. Copyright (C) 2021 American Megatrends, Inc.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Boot
Save & Exit
Set the Date. Use Tab to
switch between Date elements.
Default Ranges:
Year: 2005-2099
Months: 1-12
Days: dependent on month
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day,
from Monday to Sunday. Month displays the month, from January to
December. Date displays the date, from 1 to 31. Year displays the year, from
2005 to 2099.
to
System Time
The time format is <hour>, <minute>, <second>. The time is based on the
24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays
hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays
seconds from 00 to 59.
29
XPPC 16-101 User Manual
