Summary of Contents for Respironics BiPAP Vision

  • Page 1 Service Manual...
  • Page 2 The BiPAP Vision Ventilatory Support System is the subject of U.S. patents #5148802, #5239995, #5313937, #5433193, and other pending U.S. and foreign patents. BiPAP is a registered trademark of Respironics. Copyright © 1998 Respironics. All rights reserved.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction ..................1-1 BiPAP Vision Ventilatory Support System Overview ............1-2 Service Notice ........................1-3 Technical Support ......................1-3 Chapter 2: Warnings, Cautions, and Notes ............2-1 Warnings ..........................2-2 Cautions ..........................2-3 Notes ..........................2-4 Chapter 3: Description and Theory of Operation ..........3-1 BiPAP Vision System ......................
  • Page 4 Chapter 7: Repair and Replacement ..............7-1 Contact Information ......................7-2 Exploded View ........................7-3 BiPAP Vision Repair Kits ....................7-5 Mobile Stand II & III Repair Parts ..................7-10 Replacement Identification Photo’s ..................7-11 Touch Pad Replacement Instructions ................7-59 Chapter 8: Testing and Calibration ..............8-1...

  • Page 5: Chapter 1: Introduction

    Chapter 1: Introduction Chapter 1: Introduction BiPAP Vision Ventilatory Support System Overview....1-2 Service Notice ................1-3 Technical Support ................1-3 1015010 BiPAP Vision Service Manual...

  • Page 6: Bipap Vision Ventilatory Support System Overview

    The BiPAP Vision features a centrifugal blower to generate airflow, as well as hardware and software platforms that can be upgraded with an oxygen module and additional patient alarms. The system operates in the Continuous Positive Airway Pressure (CPAP), Pressure Support (S/T), and optional Proportional Assist Ventilation/Timed (PAV/T) modes.

  • Page 7: Service Notice

    This service manual was prepared by Respironics primarily for use by qualified technicians required to service the BiPAP Vision. 1.3 Technical Support Respironics is committed to customer satisfaction, and may be contacted with any questions or for technical support at the following numbers: U.S. and Canada...

  • Page 8: Chapter 2: Warnings, Cautions, And Notes

    Chapter 2: Warnings, Cautions, and Notes Chapter 2: Warnings, Cautions, and Notes Warnings ..................2-2 Cautions ..................2-3 Notes ....................2-4 BiPAP Vision Service Manual 1015010...

  • Page 9: Warnings

    2.1 WARNINGS 2.1.1 Safety • Do not use the BiPAP Vision in the presence of a flammable anesthetic mixture with air, oxygen, or nitrous oxide. • Oxygen supports combustion. Do not use oxygen while smoking or in the presence of an open flame.

  • Page 10: Cautions

    • Do not attempt to make connection to the diagnostic RS232 connector on the back panel of the BiPAP Vision to obtain repair information while the unit is operating on a patient. • To assure the safety of the service technician and specified performance of the device, Respironics recommends that only qualified technicians perform repairs to the BiPAP Vision.

  • Page 11: Notes

    This device contains a rechargeable nickel-cadmium (NiCAD) battery which is used by the alarms in the event of a power failure. • Refer to the BiPAP Vision Clinical Manual for a complete list of operational Warnings, Cautions, and Notes. Additional WARNINGS, CAUTIONS, and NOTES are located throughout this manual.

  • Page 12: Chapter 3: Description And Theory Of Operation

    Chapter 3: Description and Theory of Operation Chapter 3: Description and Theory of Operation BiPAP Vision Ventilatory Support System ........3-2 Power Supply Subsystem (PSS)............ 3-5 Main Control (MC)................. 3-8 Pressure Control (PC) ..............3-9 Display Control (DC) ..............3-11 Airflow Module (AFM) ..............3-14 Oxygen Module (OM) ..............

  • Page 13: Bipap Vision Ventilatory Support System

    (Refer to the BiPAP Vision Clinical Manual.) A liquid crystal display (LCD) screen is mounted on the front enclosure of the BiPAP Vision. The LCD and the Display Control (DC) board provide the primary user interface with the ventilator, including the visual presentation of data, control features, and visual and audible presentation of alarm conditions.
  • Page 14 BiPAP Vision Ventilatory Support System (Continued) Subsystem Function The Power Supply Subsystem (PSS) provides DC power to the BiPAP Vision from an AC source. The Main Control (MC) board or Main Control Subsystem (MCS) performs all control, data acquisition, and calculations required for the user-selected parameters. In addition, the MC performs the start-up test and reports all errors.
  • Page 15 Chapter 3: Description and Theory of Operation BiPAP Vision Ventilatory Support System (Continued) 1015010 BiPAP Vision Service Manual...
  • Page 16 Chapter 3: Description and Theory of Operation 1015010 BiPAP Vision Service Manual...

  • Page 17: Power Supply Subsystem (Pss)

    Safety features designed into the circuitry include an overvoltage disconnect, low voltage supply detect, and line loss detect. Other features include “power-on” indicator voltage, circulation fan power, and an On/ Off switch connection. Figure 3-2 PSS Block Diagram 1015010 BiPAP Vision Service Manual...
  • Page 18 Power Supply Subsystem (PSS) (Continued) 3.2.1 Input Range The BiPAP Vision can operate with an AC input of 100, 120, 230, or 240 VAC (±10%) depending on the model. 3.2.2 DC Supply The output DC supply is fused at 30 amps and delivers between 20.6 VDC and 35 VDC with a maximum ripple of 1 vpp (peak-to-peak voltage) to the MC, PC, and DC.

  • Page 19: Main Control (Mc)

    Intermodule Communications Bus (ICB). Nurse Call / Remote Alarm * DCS RX / TX PAS RX / TX Figure 3-3 MC Block Diagram * For S/N units >106K 1015010 BiPAP Vision Service Manual...

  • Page 20: Pressure Control (Pc)

    Acquire sensor data through an Analog-to-Digital Converters (ADC, A / D) Control valves and the blower motor through a Digital-to-Analog Converter (DAC) Respond to or invoke an error signal J15* * For Units Serial Number <106K Figure 3-4 PC Block Diagram 1015010 BiPAP Vision Service Manual...
  • Page 21 The diagnostic connector (J3) interfaces with the microprocessor to view PC functions and system errors on units from serial number 100500 to 105999, unless upgraded. For units greater than this, the diagnostic connector is on the rear of the unit. 1015010 BiPAP Vision Service Manual...

  • Page 22: Display Control (Dc)

    The displays and controls are described in more detail in the following subsections. * For Units Serial Number < 106K Figure 3-5 DC Block Diagram 1015010 BiPAP Vision Service Manual...
  • Page 23 An internal test is performed to verify the Ventilator Inoperative LED current is acceptable. 3.5.11 Error Line Control (ELC) Circuits The DC contains redundant error signaling circuitry to communicate error conditions among the subsystems. The circuitry’s redundant and diverse nature minimizes the chance of communication failures. 1015010 BiPAP Vision Service Manual...
  • Page 24 The watchdog function has to be periodically reset by the microprocessor if a time-out period has been exceeded. This function is designed to reset the processor if the software gets lost. When a low logic level is detected, the ELC will be activated resulting in a system shutdown. 1015010 BiPAP Vision Service Manual...

  • Page 25: Airflow Module (Afm)

    AFM electronic sensors. Also, a hole is molded into the flow body to position the temperature sensor. The body has molded feet for attaching it to the AFM circuit board assembly. And/Or Oxygen Supply Figure 3-6 AFM Block Diagram 1015010 BiPAP Vision Service Manual...
  • Page 26 PC board for conversion. 3.6.5 Temperature Measurement The temperature is measured using a sensor inserted into a molded hole in the flow body. The BiPAP Vision requires temperature indication to correct air density and detect an undesirable temperature rise in the patient circuit.
  • Page 27 OM must be calibrated. Calibration data is stored in a nonvolatile memory that is part of the OM. The flow indication is for the ventilator pure oxygen stream flowing through a flow body attached to the OM circuit board. Figure 3-7 OM Block Diagram 1015010 BiPAP Vision Service Manual...

  • Page 28: Description Of Ventilator Modes

    O) that determines the amount of pressure support delivered with each breath (PS = IPAP– EPAP). During the inspiratory phase, the BiPAP Vision responds as necessary to satisfy the patient’s flow require- ments while maintaining the preset IPAP pressure. Under these conditions, the patient is active in determining inspiratory time and tidal volume.
  • Page 29 3.8.3 Proportional Assist Ventilation / Timed Mode (PAV/T) For a detailed description of functioning of the Proportional Assist Ventilation/Timed (PAV/T) Mode, refer to the appropriate BiPAP Vision Clinical manual. This mode utilizes the design features of S/T mode and is a software enhancement only.
  • Page 30 Central Alarm System Open Closed Central Alarm System NOTE: Option 2 is the original factory set configuration for S/N 106001 to 106368. Option 3 is the original factory set configuration for S/N 106369 and greater. JP 2 1015010 BiPAP Vision Service Manual...

  • Page 31: Nurse Call / Remote Alarm

    Nurse Call / Remote Alarm (Continued) Details of option selections: Option 1: For use with Respironics Remote Alarm ( RI p/n 34003, or equivalent). Option 2: For use with alarm systems requiring NORMALLY OPEN contacts for an “alarm” condition and CLOSED contacts for a “no alarm”...
  • Page 32 3-21 Chapter 3: Description and Theory of Operation 3.10 BiPAP Vision Patient Disconnect Alarm Description of Operation The patient disconnect alarm (“Disconnect”) is based on the flow limit control algorithm in the Vision. The mitigation for the Disconnect alarm is to put the unit into flow limit control. This same action is done when the user selects the Standby key.
  • Page 33 That can be cleared by selecting the Alarm Reset key. Note: During FLC, the oxygen parameter setting reduces to 21%, regardless of the setting. 1015010 BiPAP Vision Service Manual...

  • Page 34: Chapter 4: Specifications And Control Ranges

    Chapter 4: Specifications and Control Ranges Chapter 4: Specifications and Control Ranges Specifications ................. 4-2 Control Ranges and Increments ............ 4-5 BiPAP Vision Service Manual 1015010...

  • Page 35: Specifications

    (For serial no.’s 100499 and lower – Respironics Recorder # 582100) 220 VAC, 230 VAC and 240 VAC ~ T 1.6 A, 250 V, 5 × 20 mm (For all serial no.’s – Respironics Recorder # 1000750) Power Consumption ......300 VA max.
  • Page 36 Degree of Protection Against Harmful Ingress of Water: Ordinary Equipment, IPX0 Electromagnetic Compatibility ........The BiPAP Vision meets the requirements of IEC 601-1-2 Earth Resistance ........ Less than 0.10 ohms Earth Leakage Current ..... Normal Pole, No Earth, L2 ..
  • Page 37 Chapter 4: Specifications and Control Ranges Specifications (Continued) TRIGGER SENSITIVITY: (Refer to BiPAP Vision Clinical Manual Auto-Trak section for more details) Spontaneous Trigger ......Shape Trigger leak Volume 6 cc above Spontaneous Cycle ......Spontaneous Expiratory Threshold (SET) Shape Cycle IPAP maximum of 3.0 sec...

  • Page 38: Control Ranges And Increments

    Chapter 4: Specifications and Control Ranges 4.2 Control Ranges and Increments NOTE: Refer to the applicable BiPAP Vision Clinical Manual for PAV/T information. 4.2.1 Parameters *With optional Oxygen Module 4.2.2 Alarms (Adjustable) Alarm Control Control Range Increments High Pressure 5 to 50 cm H...
  • Page 39 OLUME 99 L /M 1 L / M INUTE ENTILATION 300 L/M 1 L / M OTAL 300 L /M 1 L /M ATIENT 50 C NSPIRATORY RESSURE 100% ERCENT ATIENT RIGGERED REATHS TRIG 100% BiPAP Vision Service Manual 1015010...

  • Page 40: Chapter 5: Routine Maintenance

    Chapter 5: Routine Maintenance Chapter 5: Routine Maintenance Cleaning the BiPAP Vision .............. 5-2 Replacing the Inlet Filter ..............5-3 Cleaning / Replacing the Nylon Mesh Inlet Filter ......5-4 Replacing the Oxygen Regulator Filter ........... 5-6 Changing the System Fuses ............5-8 Voltage Selection ................

  • Page 41: Cleaning

    Chapter 5: Routine Maintenance 5.1 Cleaning the BiPAP Vision CAUTION: Do not immerse the BiPAP Vision in water or allow any liquid to enter the cabinet or the inlet filter. NOTE: The following guidelines for cleaning refer to the BiPAP Vision only. Refer to the individual instructions for cleaning accessories.

  • Page 42: Replacing The Inlet Filter

    Examine the inlet filter for integrity and cleanliness before each use, and as required during operation. Step 1 Turn the BiPAP Vision OFF and unplug the electrical cord from the wall outlet and from the back of the unit. Removing the Filter...

  • Page 43: Cleaning/Replacing The Nylon Mesh Inlet Filter

    A dirty nylon mesh inlet filter may cause high operating temperatures and may affect ventilator performance. Step 1 Turn the BiPAP Vision off and unplug the electrical cord from the wall outlet and from the back of the unit. Step 2 Remove the filter cap and inlet filter.
  • Page 44 If necessary, remove the protective backing from the nylon mesh inlet filter. Align the new cleaned nylon mesh inlet filter with the filter enclosure. Press the edges of the filter firmly in place. Secure the filter to the filter enclosure using the two Phillips screws. 1015010 BiPAP Vision Service Manual...

  • Page 45: Replacing The Oxygen Regulator Filter

    NOTE: Replace the filter as necessary to ensure normal operation. Step 1 Position the BiPAP Vision so that the back is easily accessible. Step 2 Disconnect the Oxygen Module (OM) input line. Step 3 Firmly grasp the plastic body of the regulator bowl and rotate it counterclockwise to remove it.
  • Page 46 Put the regulator bowl in place and rotate it clockwise until securely tightened. Step 8 Connect the oxygen input line to the OM. BiPAP Vision Oxygen Module Regulator Filter and Regulator Bowl Compatibility Note: Refer to the information below for compatibility when ordering Oxygen bowl and filter replacements.

  • Page 47: Changing The System Fuses

    Chapter 5: Routine Maintenance 5.5 Changing the System Fuses WARNING: Unplug the BiPAP Vision before changing the fuses. NOTE: This procedure applies to Vision S/N’s 100500 and greater. Step 1 Unplug the AC power cord from the wall outlet and from the power entry module on the rear of the BiPAP Vision.
  • Page 48 Use only Respironics approved fuses. See Section 5.6 for fuse part numbers. Step 8 Swing the fuse drawer door shut and snap it into place. Step 9 Plug the AC power cord into the BiPAP Vision and the wall outlet. 1015010 BiPAP Vision Service Manual...

  • Page 49: Power Cord Inspection

    5-10 Chapter 5: Routine Maintenance 5.6 Voltage and Fuse Selection The voltage selection is originally set at the factory. If you wish to use the BiPAP Vision with a different operating voltage, refer to Section 5.5. NOTE 1: Vision S / N’s 100500 and greater: •...

  • Page 50: Internal Alarm Battery

    Low Battery Condition The NiCAD battery can lose its charge if the BiPAP Vision is not used for an extended time. In a typical vironment, a fully charged battery can be stored approximately six months before losing its charge, but the discharge rate depends heavily on temperature.
  • Page 51 Allow the unit to remain in the Exhalation Port/Language selection screen. Or, allow the unit to be in therapy or Standby mode. Leave in one of these conditions for approximately 24 hours to fully charge the battery. 1015010 BiPAP Vision Service Manual...
  • Page 52 If not, then the unit is ready for use. CAUTION: Prolonged storage of the BiPAP Vision at high temperatures, above 80 ºF (27 ºC) can result in premature battery failure. Failure to recharge a battery when it is being stored for long periods will cause a loss of battery life, activate the Check Ventilator alarm, and generate error code 205.

  • Page 53: Preventive Maintenance Schedule

    Test Alarms. 1 Year Run Blower Valve Section 8.5 Calibration Perform “System Section 8.8 1 Year Final Test” Inspect Power Section 5.1 As required Cord As required Section 5.7 Cleaning Tested by: ________________________________ Date: _______________ 1015010 BiPAP Vision Service Manual...

  • Page 54: Chapter 6: Troubleshooting

    Chapter 6: Troubleshooting Chapter 6: Troubleshooting Overview ..................6-2 Description of System Alarms ........... 6-5 Alarm Indicators ................. 6-7 Troubleshooting ................6-8 Check VentError Codes ............6-12 Vent Inop Errors ................ 6-14 1015010 BiPAP Vision Service Manual...

  • Page 55: Overview

    Chapter 6: Troubleshooting 6.1 Overview Purpose This chapter outlines a general procedure for troubleshooting the BiPAP Vision. Problems shall be investigated to the major component or subassembly as indicated on the specific error code charts found in this chapter. Process...
  • Page 56 Chapter 6: Troubleshooting 1015010 BiPAP Vision Service Manual...
  • Page 57 Chapter 6: Troubleshooting BiPAP Vision Service Manual 1015010...

  • Page 58: Description Of System Alarms

    Chapter 6: Troubleshooting 6.2 Description of System Alarms The BiPAP Vision incorporates self-diagnostic testing capabilities and a number of safety features. All system internal functions are checked automatically at start up and periodically throughout operation. The microprocessors continuously obtain readings from internal sensors to monitor machine functions and operating conditions.
  • Page 59 The visual patient alarm indicator in the Mode / Message Area is cancelled only when the ALARM RESET hard key is pressed. The ALARM RESET hard key cancels the alarm silence period and resets the visual indicators. The alarm immediately reactivates if the condition causing the alarm has not been corrected. BiPAP Vision Service Manual 1015010...

  • Page 60: Alarm Indicators

    ALARM SILENCE hard key. However, the visual indicator cannot be reset and remains illuminated until the error is corrected. The ventilator continues to operate during a “Check Ventilator” condition. Active: At all times. 1015010 BiPAP Vision Service Manual...

  • Page 61: Troubleshooting

    Chapter 6: Troubleshooting BiPAP Vision Service Manual 1015010...
  • Page 62 Chapter 6: Troubleshooting Troubleshooting (Continued) 1015010 BiPAP Vision Service Manual...
  • Page 63 6-10 Chapter 6: Troubleshooting Troubleshooting (Continued) BiPAP Vision Service Manual 1015010...
  • Page 64 6-11 Chapter 6: Troubleshooting Troubleshooting (Continued) 1015010 BiPAP Vision Service Manual...

  • Page 65: Check Venterror Codes

    6-12 Chapter 6: Troubleshooting 6.5 Check Vent Error Codes Perform Testing according to the "Recommended Testing after Part(s) Replacement" found in Chapter 8 Figure 6-3 Check Vent Error Flow Chart BiPAP Vision Service Manual 1015010...

  • Page 66: Error Codes

    6-13 Chapter 6: Troubleshooting Error Codes (Continued) 1015010 BiPAP Vision Service Manual...

  • Page 67: Vent Inop Errors

    Errors, make sure that errors on the PC, MC and DC are noted. If any indicate a hardware or therapy delivery suspected problem, follow this course of action. Figure 6-4 Vent Inop Indicator Troubleshooting Flow Chart BiPAP Vision Service Manual 1015010...
  • Page 68 Errors, make sure that errors on the PC, MC and DC are noted. If any indicate a hardware or therapy delivery suspected problem, follow this course of action. Figure 6-5 Vent Inop Indicator Troubleshooting Flow Chart 1015010 BiPAP Vision Service Manual...
  • Page 69 6-16 Chapter 6: Troubleshooting Vent Inop Errors (Continued) BiPAP Vision Service Manual 1015010...
  • Page 70 6-17 Chapter 6: Troubleshooting Vent Inop Errors (Continued) 1015010 BiPAP Vision Service Manual...
  • Page 71 6-18 Chapter 6: Troubleshooting Vent Inop Errors (Continued) BiPAP Vision Service Manual 1015010...
  • Page 72 6-19 Chapter 6: Troubleshooting Vent Inop Errors (Continued) 1015010 BiPAP Vision Service Manual...
  • Page 73 6-20 Chapter 6: Troubleshooting Vent Inop Errors (Continued) BiPAP Vision Service Manual 1015010...
  • Page 74 6-21 Chapter 6: Troubleshooting Vent Inop Errors (Continued) 1015010 BiPAP Vision Service Manual...
  • Page 75 6-22 Chapter 6: Troubleshooting Vent Inop Errors (Continued) BiPAP Vision Service Manual 1015010...
  • Page 76 6-23 Chapter 6: Troubleshooting Vent Inop Errors (Continued) 1015010 BiPAP Vision Service Manual...
  • Page 77 6-24 Chapter 6: Troubleshooting Vent Inop Errors (Continued) BiPAP Vision Service Manual 1015010...
  • Page 78 Internal Analog to Digital Converter Intermodule Communications Bus ILFR In-Line Flow Restrictor Liquid Crystal Display Light Emitting Diode Low PCs Filter Main Control Microcontroller Unit Microprocessor Multiplexer Negative Acknowledgment NVRAM Non-Volatile Random Access Memory Oxygen Oxygen Module 1015010 BiPAP Vision Service Manual...
  • Page 79 Pressure Release Valve Queued Serial Module Queued Serial Peripheral Interface Random Access Memory Read Only Memory Revolutions Per Minute Real Time Clock Serial Interface Serial Peripheral Interface Tack Acknowledge Timer Trply Reply Timer Vref Voltage Reference BiPAP Vision Service Manual 1015010...

  • Page 80: Chapter 7: Repair And Replacement

    Chapter 7: Repair and Replacement Contact Information ............... 7-2 Exploded View ................7-3 BiPAP Vision Repair Kits ............... 7-5 Mobile Stand II and III Repair Parts ..........7-10 Replacement Identification Photo’s ..........7-11 Touch Pad Replacement Instructions .........7-59 BiPAP Vision Service Manual...

  • Page 81: Contact Information

    Chapter 7: Repair and Replacement 7.1 Contact Information Figures 7-1 and 7-2 list the names and identify the locations of major replaceable components in the BiPAP Vision. These drawings provide a quick reference and overview of the unit. Note: Refer to Section 8.2 for testing that is required after items are replaced.

  • Page 82: Exploded View

    Chapter 7: Repair and Replacement 7.2 Exploded View Figure 7-1 BiPAP Vision Ventilator Component Location and Identification BiPAP Vision Service Manual 1015010...
  • Page 83 Chapter 7: Repair and Replacement Exploded View (Continued) Figure 7-2 Front Panel Assembly Exploded View * Not available as a repair kit, contact Technical Support for assistance. BiPAP Vision Service Manual 1015010...

  • Page 84: Bipap Vision Repair Kits

    Chapter 7: Repair and Replacement 7.3 BiPAP Vision Repair Kits Replacement Kit Replacement Part No. Photo Page No. AC Inlet (includes power inlet filter) 582138 7-13,7-14 AC Power Cord (North American) (See Note 2) 362435 Not Shown AC Power Cord Clamp...

  • Page 85: Bipap Vision Repair Kits

    Chapter 7: Repair and Replacement BiPAP Vision Repair Kits (Continued) Replacement Kit Replacement Part No. Photo Page No. EPROM Extraction Tool Kit 1006874 Not Shown Front Panel Enclosure 582135 7-54 Fuses, 115VAC, S/N <100500 582100 Not Shown (Also part of upgrade Fuses, 100-120 Volt, S/N >100499...
  • Page 86 Chapter 7: Repair and Replacement BiPAP Vision Repair Kits (Continued) Replacement Kit Replacement Part No. Photo Page No. MC/DC Cable S/N>106K 1004698 7-28 MC Board S/N>106K (see note3,4) 1004711 7-34,7-36 Mobile Stand III Shipper 1009410 Not Shown Mobile Stand III drawer feet...
  • Page 87 Chapter 7: Repair and Replacement BiPAP Vision Repair Kits (Continued) Replacement Kit Replacement Part No. Photo Page No. Shipping Container 1002424 Not Shown (includes all necessary inner packaging) Test Cable(S/N <106K) (see section 8.10) 582161 7-58 Test Cable (Ribbon) 1004699 7-17,7-19,7-27, (or RS232 Ribbon Harness for S/N >106k)
  • Page 88 NOTE 1: All items have a quantity of one unless otherwise specified. NOTE 2: For specific country AC power cord ordering information, please contact Respironics Customer Service. NOTE 3: The original EPROM must be removed from the circuit board and installed into the new circuit board, unless performing an upgrade to units S/N<106K.
  • Page 89 Replacement Part No. Humidifier Bracket 1005101 O2 Hose Hanger Assembly 1007903 Oxygen Analyzer Pole 1011515 Storage Compartment 1007904 Mobile Stand III Storage Tray 1007905 Mobile Stand III Shipper 1009410 Mobile Stand III Storage Tray Feet 1009745 BiPAP Vision Service Manual 1015010...

  • Page 90: Replacement Identification Photos

    The following identification photos are to be used as repair guidelines. Items have been identified for all serial number units beginning with 100500 to present. Pressure Control Board S/N >106K (1004710) EPROM S/N >106K (1000353) (W/ PAV 1000354) BiPAP Vision Service Manual 1015010...
  • Page 91 7-12 Chapter 7: Repair and Replacement Pressure Air Flow Subsystem Note: This item is obsolete, originally P/N 582146. Replaced by 1004713 for units S/N <106001. BiPAP Vision Service Manual 1015010...
  • Page 92 RS232 Diagnostic Connector Oxygen Module Model Number Manifold/Regulator Bowl Serial Number (582154) AC Inlet Bottom Enclosure Power Cord Clamp (1007546) (582138) S/N >106K (1000751) (1004700) Main Power Switch (now comes with a spring loaded cover.) (582141) BiPAP Vision Service Manual 1015010...
  • Page 93 7-14 Chapter 7: Repair and Replacement Fuses and Voltage Selector Fuse Location AC Inlet (582138) Voltage Setting Fuses (1000749 for 100 and 120 VAC Operation 1000750 for 230 and 240 VAC operation) 1015010 BiPAP Vision Service Manual...
  • Page 94 7-15 Chapter 7: Repair and Replacement Inlet Filter Enclosure (582134) Inlet Mesh Filter (1000747) Inlet Filter Cover Inlet Filter (x6) (1003444) (582101) BiPAP Vision Service Manual 1015010...
  • Page 95 7-16 Chapter 7: Repair and Replacement Exploded View (Continued) Circulation Fan Muffler (English 582155) (Int’l 1005618) Standoff(s) (x4)* Label, Diagnostic Nurse Call S/N >106K Screws (x4) * (1004703) Circulation Fan Muffler * Included 1015010 BiPAP Vision Service Manual...
  • Page 96 Display Control (DC) S/N >106K (1004709) Alarm Battery Liquid Crystal Display (1012819) (582139) Located under the DC/LCD Mounting plate RS232 Harness S/N >106K (1004699) DC Power Connection S/N >106K Ground Connection Rotary Encoder ICB Cable S/N >106K (582148) (1004695) BiPAP Vision Service Manual 1015010...
  • Page 97 Chapter 7: Repair and Replacement DC View #2 S/N >106K LCD Backlight Main Power Indicator Voltage Connection Cable Connection (Connects either way) (Connects either way) DCS/LCD Mounting Audible Alarm Bracket Connection Rotary Encoder Connection ICB Cable S/N >106K (1004695) 1015010 BiPAP Vision Service Manual...
  • Page 98 Chapter 7: Repair and Replacement Component Identification ICB Cable S/N >106K (1004695) Air Flow Module (582127) Ground Wire Coiled Pressure Tubing (1000752) Audible Alarm Main Power (1000743) RS 232 Harness S/N >106K Indicator Connector (1004699) BiPAP Vision Service Manual 1015010...
  • Page 99 7-20 Chapter 7: Repair and Replacement Component Identification Inlet Filter Enclosure Assembly Blower Muffler (582134) (582129) Oxygen Module Assembly (English 582142) (Int’l 1005619) Blower Assembly (582128) 1015010 BiPAP Vision Service Manual...
  • Page 100 7-21 Chapter 7: Repair and Replacement Blower Assembly (582128) Blower Mounting Brackets (x3) Blower Blower Vibration Isolators (x3) (1003893) Heat Sink* Dampener* Blower Connection to PC * Not sold seperately BiPAP Vision Service Manual 1015010...
  • Page 101 7-22 Chapter 7: Repair and Replacement Front Panel Assembly Error LED DC Subsystem Main Power Indicator Connector LCD / DC Cable Keypad Cable Ground Connection Audible Alarm DC Power Connector Battery ICB Connector Rotary Encoder 1015010 BiPAP Vision Service Manual...
  • Page 102 7-23 Chapter 7: Repair and Replacement DC Cable Connections DC EPROM LCD / DC Cable Keypad Ribbon Cable Rotary Encoder (582148) BiPAP Vision Service Manual 1015010...
  • Page 103 7-24 Chapter 7: Repair and Replacement Front View DC Subsystem (1004709, or part of 1004707, 1004714) DC EPROM Error LED 1015010 BiPAP Vision Service Manual...
  • Page 104 7-25 Chapter 7: Repair and Replacement Back View DC Subsystem (1004709, or part of 1004707, 1004714) Audible Alarm Battery Audible Alarm Keypad Connection Connection Power Supply Rotary Encoder Connection Connection ICB Connector BiPAP Vision Service Manual 1015010...
  • Page 105 Blower / ILFR Coupler Inlet Filter (1003728) Enclosure (582134) AC Inlet to Transformer Connection Main Power Switch Oxygen Baffle (582141) (1004705) Nurse Call/ Remote Alarm Connector (1004697) Power Supply Subsystem (PSS) Transformer (582145) Assembly (582152) 1015010 BiPAP Vision Service Manual...
  • Page 106 RS 232 Harness S/N>106K (582145) (1004699) Nurse Call / Remote Alarm Harness (1004697) Circulation Fan (582132) PC Subsystem PC to DC Power Connection Power Harness PSS/PC S/N >106K Transformer Assembly (1004706) (582152) Main Power Switch Connection to PSS BiPAP Vision Service Manual 1015010...
  • Page 107 7-28 Chapter 7: Repair and Replacement DC Cables RS 232 Cable S/N >106K ICB Cable S/N >106K (1004698) (1004695) Power Harness PC / DC S/N >106K (1004696) 1015010 BiPAP Vision Service Manual...
  • Page 108 Oxygen Valve (English 582142) (Part of Kit 1014434) (Int’l 1005619) Oxygen to PC Ribbon Cable Oxygen Valve Connection Pressure Regulation Valve (PRV) (582147) Thermister In-Line Flow Restrictor Valve Ac Inlet to Transformer Connection (ILFR) (582137) BiPAP Vision Service Manual 1015010...
  • Page 109 PSS to PC Power Cable (1004706) PSS Subsystem (582145) Coiled Pressure Tube (1000752) AFM to PC Ribbon Cable OM to PC Ribbon Cable Reduadant Pressure Sensor Audible Alarm (1000743) ICB Cable S/N >106K Error LED (1004695) 1015010 BiPAP Vision Service Manual...
  • Page 110 7-31 Chapter 7: Repair and Replacement Component Identification Oxygen Baffle (1004705) Air Flow Module (582127) Coiled Pressure Tubing Transformer Assembly (1000752) (582152) ICB Cable Audible Alarm (1004695) (1000743) BiPAP Vision Service Manual 1015010...
  • Page 111 7-32 Chapter 7: Repair and Replacement Oxygen Module Assembly (English, 582142) (Int’l 1005619) Regulator/Manifold Assembly 1014434 Flow Body / PCA 1014433 Inlet Fitting (DISS) 1014805 1015010 BiPAP Vision Service Manual...
  • Page 112 Power Supply Connector Redundant Pressure Sensor Power Supply to ICB connector DC Connector AFM Connector Oxygen Module Connector Error LED EPROM * Also part of 1004713, used to upgrade units S/N<106K 1000356, 1004714 and 1004707 BiPAP Vision Service Manual 1015010...
  • Page 113 Main Control (MC) Subsystem* (1004711) Nurse Call / Remote Alarm Connector RS 232 Connector EPROM Error LED Alarm PAL (582158) RS 232 to DC Subsystem Connection * Also part of 1004713, 1000356, 1004714 and 1004707 1015010 BiPAP Vision Service Manual...
  • Page 114 7-35 Chapter 7: Repair and Replacement Component Identification Inline Flow Restrictor Valve (ILFR) (582137) Pressure Regulation Valve (PRV) (582147) Oxygen Baffle (1004705) BiPAP Vision Service Manual 1015010...
  • Page 115 Nurse Call / Remote Alarm Connector (1004697) RS 232 Connector (1004699) Alarm PAL (582158) EPROM Battery S/N >106K (1006005) Error LED * Also part of 1004713, 1000356, 1004714 and 1004707 used to upgrade units S/N<106K 1015010 BiPAP Vision Service Manual...
  • Page 116 Chapter 7: Repair and Replacement Air Flow Module (AFM) (582127) Pressure Sensor Thermistor Flow Sensor Connects to the PC Connects to the redundant pressure sensor on the PC Oxygen Baffle (1004705) Arrow towards front of unit, gas flow direction. BiPAP Vision Service Manual 1015010...
  • Page 117 Power Supply Subsystem (PSS) (582145) Power Supply connection to PC Subsystem Main Power Switch Connection (582141) Transformer Connection Main Power LED, Circulation Fan Current Sense, Connects to the Front Panel Connects to PC Circulation Fan Power Connection 1015010 BiPAP Vision Service Manual...
  • Page 118 7-39 Chapter 7: Repair and Replacement Valve Identification In-Line Flow Pressure Regulation Restrictor Valve Valve (PRV) (ILFR) (582137) (582147) Connect to PC Subsystem BiPAP Vision Service Manual 1015010...
  • Page 119 7-40 Chapter 7: Repair and Replacement Transformer Assembly (582152) Connection to AC Inlet Connection to PSS Metal Retaining Plate Bottom Insulation Spacer Top Insulation Spacer Retaining Nut 1015010 BiPAP Vision Service Manual...
  • Page 120 Nurse Call / Remote Alarm Ac Inlet / EMI Filter (1004697) (582138) RS 232 Connector (1004699) Grounding Stud Connects to PSS Bottom Enclusure S/N >106K (1004700) Connections to MC (Nurse Call / Remote Alarm) Connects to PSS BiPAP Vision Service Manual 1015010...
  • Page 121 7-42 Chapter 7: Repair and Replacement Nurse Call / Remote Alarm, RS 232 Cable rounting 1015010 BiPAP Vision Service Manual...
  • Page 122 (582134) Oxygen Module (English, 582142) (Int’l, 1005619) Main Power Switch (582141) Circulation Fan Muffler (English, 582155) (Int’l, 1005618) Bottom Enclosure S/N <106K (582130) Rubber Feet (x4) AC Power Cord Clamp AC Inlet (582149) (1000751) (582138) BiPAP Vision Service Manual 1015010...
  • Page 123 7-44 Chapter 7: Repair and Replacement Display Control Subsystem (D/CS) Connections for S/N <106001 (582133) ICB Cable S/N < 106K Power Supply Connection Rotary Encoder Connection Audible Alarm Connection 1015010 BiPAP Vision Service Manual...
  • Page 124 LCD Power Connection (Connects either way) Main Power Indicator Audible Alarm LED Connection Connectrion (Connects either way) Rotary Enoder Connection ICB Cable Connection * Also could be for upgrade units S/N <106K using 1004714 or 1004707 BiPAP Vision Service Manual 1015010...
  • Page 125 Chapter 7: Repair and Replacement Display Control Subsystem (D/CS) (582133) Error LED ICB Connector LCD Backlight Connector Main Power Connector DCS/LCD Connector Keypad Connector Rotary Encoder Connector Power Connector ICB Connector Placement for Upgraded Units 1015010 BiPAP Vision Service Manual...
  • Page 126 7-47 Chapter 7: Repair and Replacement Display Control Subsystem (D/CS) (582133) LCD Backlight RS 232 Test Cable Connector Connector (connect either direction) EPROM (1000286 Non PAV S/N <106K) (1003524 W/PAV S/N <106K) BiPAP Vision Service Manual 1015010...
  • Page 127 (connects either direction) RS 232 Test Cable Connector Audible Alarm Battery Keypad Connector ICB Connector Audible Alarm Connector Rotary Encoder Connector Power Connections ICB Connector placement for upgraded units (Part of upgrade kit 1004713 or 1000356, PAV) 1015010 BiPAP Vision Service Manual...
  • Page 128 (582142) (582128) Air Flow Module Power Supply (582127) Subsystem (582145) Coiled Pressure Tubing (1000752) Bottom Enclosure S/N <106K (582130) MCS* PAS* ICB Cable S/N <106K (582159) * Replaced using upgrade kit 1004713, or 1000356 (PAV) BiPAP Vision Service Manual 1015010...
  • Page 129 Chapter 7: Repair and Replacement Component Identification (S/N <106K) Power Connections Transformer (582152) MCS Error LED MCS RS 232 Test Cable Connection PAS Blower Connection Patient Pressure Sensor Unit Outlet Pressure Sensor PAS Error LED 1015010 BiPAP Vision Service Manual...
  • Page 130 PRV Valve Connector Blower Connector Circulation Fan Current Sense Connector Patient Pressure Sensor AFM Connector Oxygen Module Connector RS 232 Connector Unit Outlet Pressure ICB Cable Connector Error LED EPROM S/N <106K (1000286) (1003524 W/PAV) BiPAP Vision Service Manual 1015010...
  • Page 131 7-52 Chapter 7: Repair and Replacement Inlet Foam Strip Location Inlet Filter Foam Strip Inlet Filter Enclosure (1004493) (582134) 1015010 BiPAP Vision Service Manual...
  • Page 132 (No longer manufactured, now part of upgrade kit 1004713 or 100356, PAV for S/N<106K) Power Connection Error LED RS 232 Test Cable Connection Battery, Lithium (1001988) ICB Cable Connection Alarm PAL EPROM S/N <106K MCS to D/CS Ground Wire (1000286) (1003524 W/PAV) BiPAP Vision Service Manual 1015010...
  • Page 133 7-54 Chapter 7: Repair and Replacement Component Identification Front Enclosusre (582135) Rotary Encoder Knob (582157) Keypad (English, 582151) (Universal Symbols, 1004712) (German, 582221) Note: See “Touchpad Replacement Instructions at end of chapter, section 7.6 1015010 BiPAP Vision Service Manual...
  • Page 134 7-55 Chapter 7: Repair and Replacement Component Identification Bottom Enclosure S/N <106K (582130) Bottom Enclosure S/N >106K (1004700) PRV Muffler Rubber Feet (x4) (582156) (582149) BiPAP Vision Service Manual 1015010...
  • Page 135 7-56 Chapter 7: Repair and Replacement LCD Assembly (582139) LCD Backlight 1014432 Connects to DC Subsystem (Keypad) Connects to DC Subsystem (Connects either direction) 1015010 BiPAP Vision Service Manual...
  • Page 136 7-57 Chapter 7: Repair and Replacement Blower Valve Coupler (1003728) BiPAP Vision Service Manual 1015010...
  • Page 137 Upgraded to Hybrid. (1004699) Test Cable, Units S/N < 106K ( 582161) Test Cable, Units S/N > 106K and Upgraded Units S/N < 106K Hybrid (1004823) * See Section 8.10, Test Cable Usage Definitions, for further information. 1015010 BiPAP Vision Service Manual...

  • Page 138: Touch Pad Replacement Instructions

    WARNING: Electrical shock hazard: Disconnect the electrical supply before attempting to make any repairs to the device. CAUTION: Electronic components used in this device are subject to damage from static electricity. Repairs made to this device must be performed only in an antistatic, ESD-protected environment BiPAP Vision Service Manual 1015010...
  • Page 139 D / CS upwards. Gently remove the ribbon cable from (J6). Remove the one D / CS mounting screw that has touch pad shielding foil and ground wire under it. Locate the foil away from this connection. Screws 1015010 BiPAP Vision Service Manual...
  • Page 140 With the touch pad facing down, place a small amount of isopropyl alcohol between the touch pad lens and the front panel enclosure at its smallest width (near the top). Tilt the front panel enclosure slightly, and allow it to sit for approximately 10 to 15 seconds. BiPAP Vision Service Manual 1015010...
  • Page 141 (but is not secured) on the left side of the front panel enclosure. Align the touch pad, top to bottom, and rest it in place. Observe alignment as the touch pad becomes secured to the front panel enclosure. 1015010 BiPAP Vision Service Manual...
  • Page 142 Installing the D / CS - Touch Pad Ribbon Cable With the tabs fully extended on (J6), place the ribbon cable completely into the connector. While applying slight inward pressure on the ribbon cable, lock the tabs on both sides of (J6). BiPAP Vision Service Manual 1015010...

  • Page 143: Chapter 8: Testing And Calibration

    Blower/Valve Calibration Procedure ..........8-10 Performance Verification .............. 8-12 Run-In Cycle Procedure ............... 8-16 System Final Test ................. 8-18 PC or Laptop Setup Procedures ..........8-37 8.10 Test Cable Usage Definitions ............8-40 8.11 Oxygen Flow Module Test ............8-41 BiPAP Vision Service Manual 1015010...

  • Page 144: Overview

    Run-In Cycle Procedure This procedure is to be used after servicing the BiPAP Vision as called out in the Testing after Part(s) Replacement on page 8-3 and 8-4. The unit will cycle for one half hour with specified operating parameters to qualify the repair after a component has been replaced.

  • Page 145: Recommended Testing After Part(S) Replacement

    22. Oxygen Module Assembly (OM) 23. OM Regulator Bowl 24. OM Regulator Filter 25. Main Power Switch 26. Power Supply Subsystem (PSS) 27. Pressure Control (PC) 28. Pressure Relief Valve (PRV) 29. PRV Muffler 30. Rotary Encoder BiPAP Vision Service Manual 1015010...

  • Page 146: Exhalation Port Test

    32. Rubber Feet 33. Top Enclosure 34. Touch Pad 35. Transformer 36. Power Line Filter 37. Audible Alarm 38. EPROM 39. PAV / T 40. Oxygen Manifold/Regulator 41. Oxygen PCA/Flowbody 8.3 Exhalation Port Test Figure 8-1 1015010 BiPAP Vision Service Manual...
  • Page 147 Turn the main power switch to the On position and wait for the unit to complete the SYSTEM SELF TEST (internal system check). This will take approximately 5 to 15 seconds. The TEST EXHALATION PORT screen will then be displayed. BiPAP Vision Service Manual 1015010...
  • Page 148 Languages Total Operating Time: 22 HRS PRESS "MONITORING" TO EXIT PRESS "MONITORING" TO EXIT Figure 8-2 Exhalation Port Test Instructions This test can be canceled at anytime by pressing the Cancel Test soft key. NOTE: 1015010 BiPAP Vision Service Manual...
  • Page 149 The leak rate was intermittently high during the test. Check that the internal and external circuit is occluded and properly sealed. Replace, in order, the PRV valve and PC. Repeat the Exhalation Port Test between each replacement. BiPAP Vision Service Manual 1015010...

  • Page 150: Total Operating Hours Transfer Procedure

    After the time is correctly set, turn the power switch off, remove the terminal from the MC, reassemble the unit, or continue with testing process. * This is used primarily when a Main Control Subsystem or Lithium battery is replaced. 1015010 BiPAP Vision Service Manual...
  • Page 151 Chapter 8: Testing and Calibration Figure 8-3 For Visions with S/N < 106K Figure 8-4 For Visions with S/N > 106K BiPAP Vision Service Manual 1015010...

  • Page 152: Blower / Valve Calibration Procedure

    8.5 Blower / Valve Calibration Procedure Purpose This procedure provides instructions for calibrating the Blower and Valves for the BiPAP Vision system. This test will take about 10 minutes or less depending on the software version. Note: Unit must be a minimum software revision of 11.8 / 12.4 / 13.4 to successfully pass this test. If necessary upgrade unit.
  • Page 153 All of this information is stored in memory and is used to ensure that the blower and the valves are able to meet the specified requirements. BiPAP Vision Service Manual 1015010...

  • Page 154: Performance Verification

    Step 1 First connect the smooth inner lumen tubing to the unit outlet then the whisper swivel and finally the test orifice. Connect the pressure tubing from the BiPAP Vision to the test orifice. NOTE: If the Vision unit loses power, and power is restored in less than 10 seconds, the unit will return to operation at the same settings that were in effect before power was lost.
  • Page 155 MONITORING hard key then press the PARAMETERS hard key. In either case, set theparameters as follows: IPAP = 15 cm H EPAP = 5 cm H Rate = 15 BPM Timed Insp = 1.0 sec IPAP Rise Time = 0.1 sec BiPAP Vision Service Manual 1015010...
  • Page 156 20 seconds to verify that the audible tone and the Apnea Alarm Message are activated. Adjust the Apnea setting to the Disabled setting. Press the Alarm Reset key to clear the visual alarms. Step 14 Test complete. 1015010 BiPAP Vision Service Manual...
  • Page 157 (Respironics use only) Model Number Total Operating Time Purpose: This data sheet is to be used in conjunction with the BiPAP Vision Performance Verification. It should also be used whenever a screening procedure is required on the BiPAP Vision. Results:...

  • Page 158: Run-In Cycle Procedure

    8.7 Run-In Cycle Procedure Purpose This procedure is to be used after servicing the BiPAP Vision as called out in the Recommended Testing after Part(s) Replacement Chart in section 8.3. The unit will cycle for one half hour, with specified operating parameters, to qualify the repair after a component has been replaced.
  • Page 159 Verify that the display values match the set values and that no alarms occurred during this time period. If a problem exists, follow the appropriate Troubleshooting Flow Chart in Chapter 6 and perform the Run-In Cycle Procedure again before proceeding. Step 7 Test Complete. BiPAP Vision Service Manual 1015010...

  • Page 160: System Final Test

    • Test cable (P/N 582161 for serial numbers 105999 and less, P/N 1004823 for serial numbers 106000 and higher or upgraded units). • Multiple outlet power strip • Plug, cap, or stopper • Pressure pick-off port (0 port, P/N 312710) 1015010 BiPAP Vision Service Manual...
  • Page 161 Connect the Test Cable from the PC board (J3), or the Test Cable connector labeled PC, to the PC/ laptop com port. Step 3 Plug in the AC power cord and verify the MAIN POWER indicator is lit. BiPAP Vision Service Manual 1015010...
  • Page 162 Step 3 If ALARM MODULE B is installed, set the alarms as listed below (they will be displayed on the right side of the alarms screen). ALARM VALUE Lo Min Vent Disabled High Rate Low Rate 1015010 BiPAP Vision Service Manual...
  • Page 163 On the PC/Laptop type, in sequence, the capital letters SJL to view the system parameters of the Vision unit being tested. Note that only the blinking cursor will be displayed. (If required, use the PC/Laptop Setup Procedure found in Chapter 8) BiPAP Vision Service Manual 1015010...
  • Page 164 Leave the CPAP pressure set to 20 cm H Step 2 Set the flow restrictor for 0 LPM (+0.5) flow rate. Step 3 Record the flow meter reading. Step 4 Record the COMPENSATED TOTAL FLOW from the PC/Laptop. 1015010 BiPAP Vision Service Manual...
  • Page 165 100 L/Min and a rate of approximately 30 BPM (one every two seconds). While doing this, observe the manometer reading. Step 10 Verify the manometer reading to be within ± 2 cm H O of the unit’s set value. BiPAP Vision Service Manual 1015010...
  • Page 166 8-24 Chapter 8: Testing and Calibration Figure 8-7 1015010 BiPAP Vision Service Manual...
  • Page 167 Step 6 If desired, press the key for Time at P to reset. Step 7 Press System Info and record the software version, if the Oxygen Module is installed, and which Alarm Module is installed. BiPAP Vision Service Manual 1015010...
  • Page 168 Verify that the unit powers up without alarming. NOTE: For software versions 11.2 and higher, the “Loss of AC Power” indication will be flashing in the display area. Press the Alarm Reset to clear and continue. Step 7 Turn off the unit. 1015010 BiPAP Vision Service Manual...
  • Page 169 Purpose: 1. To perform an additional test on BiPAP Vision units from serial number 107401 to 108343 (inclusive). This procedure must be done the first time a Vision that falls within the above listed serial number range is returned for service for any reason. This procedure is to be performed after the unit passes system final test found in the service manual.
  • Page 170 . = 1.0 sec IMED IPAP R = .05 sec ISETIME O2% = 21% 8.) Press MONITORING button. 9.) Close the oxygen tank valve. 10.) Turn power off and disconnect test equipment. 11.) Test Complete 1015010 BiPAP Vision Service Manual...
  • Page 171 On the unit, press Parameters and set the following unit parameters. IPAP = 20 cm H EPAP = 4 cm H RATE = 15 BPM Timed Insp. = 1.0 sec IPAP Risetime = .05 sec % = 21% BiPAP Vision Service Manual 1015010...
  • Page 172 8-30 Chapter 8: Testing and Calibration Figure 8-8 1015010 BiPAP Vision Service Manual...
  • Page 173 Step 16 Close the O cylinder valve. Disconnect the O input line. NOTE: If O Module Test Fails, perform the “Oxygen Flow Module Test” found in section 8.11. Then re-run step K above. BiPAP Vision Service Manual 1015010...
  • Page 174 Measure and record the Reverse Pole, No Earth, No L2 earth leakage current. The value must be less than 1,000 microamps to pass. Step 4 Measure and record the Normal Pole, No Earth, No L2 earth leakage current. The value must be less than 1,000 microcamps amps. 1015010 BiPAP Vision Service Manual...
  • Page 175 Chapter 8: Testing and Calibration System Final Test (Continued) BiPAP Vision Nurse Call / Remote Alarm Feature Testing ( for units s/n greater than 106000 only). (optional test) Note: Refer to chapter 3 of this manual for details of the operation of this feature.
  • Page 176 Measure the continuity on the same connector and it now should be a closed circuit. Turn unit off. Upon completion, set the unit to the desired option. Final Test Data Sheet Step 1 Sign and date completed Final Test Data Sheet. 1015010 BiPAP Vision Service Manual...
  • Page 177 8-35 Chapter 8: Testing and Calibration BiPAP Vision Final Test Data Sheet Serial Number Model Number Total Operating Time Service Notification Power Indicator and LCD Controls Step Control Pass Fail Power Indicator Brightness Contrast Pressure Accuracy (see step E-3 for guidlines)
  • Page 178 Rev. Pol, No Earth, L2 < 1,000 microamps Norm Pol, No Earth, No L2 < 1,000 microamps Nurse Call/Remote Alarm (optional test for S/N > 106000) Step Pass Fail Testing Verification Tested By: (Full Signature) Date 1015010 BiPAP Vision Service Manual...

  • Page 179: Pc/Laptop Set-Up Procedure

    Purpose This procedure is to be used to set up the PC / Laptop required for testing and troubleshooting of the BiPAP Vision. Note: The vision requires no special data acquisition software. All necessary software is contained within the unit.
  • Page 180 Step 4 Again under Settings, open Terminal Preferences then set the following: Line Wrap; On Columns; 80 Cursor; Block, Blink Show Scroll Bars Use function arrows and control (Ctrl) keys for Windows. Step 5 Click OK 1015010 BiPAP Vision Service Manual...
  • Page 181 DC error code information (DC subsystem connection).* Check Vent error code history (MC subsystem connection). For determining type of breath triggering (MC subsystem connection). * If the unit is in a Vent Inop condition, the current error will automatically appear. BiPAP Vision Service Manual 1015010...

  • Page 182: Test Cable Usage Definitions

    Vision unit during use. For Vision units serial number >106K Test Cable 1004823 is to be used to test/calibrate BiPAP Vision units with serial numbers >106K. A standard serial I/O cable is used in conjunction with this to connect to the PC/laptop.
  • Page 183 Adjust R41 for a value of 0.225 to 0.235 volts DC. Re-assemble unit (if necessary) NOTE: If the measured Oxygen concentration is still not in specification after completion of this test, follow standard repair practices to obtain acceptable results. BiPAP Vision Service Manual 1015010...

  • Page 184: Oxygen Baffle Installation Instructions

    Chapter 9: Option Installation Instructions Chapter 9: PAV/T or EPROM Upgrade Installation Instructions PAV/T Mode or EPROM Upgrade Installation ..............9-2 Oxygen Baffle Installation Instructions (for units S/N <106K) ..........9-6 1015010 BiPAP Vision Service Manual...
  • Page 185 Chapter 9: Option Installation Instructions 9.1 BiPAP Vision PAV / T Mode or EPROM Upgrade Installation Included in Upgrade Kits Tools Required EPROM (DC or DCS) Phillips screwdriver EPROM (PC or PAS) Long-shaft, small, flat-blade EPROM (MC or MCS) Extraction Tool...
  • Page 186 Ensure proper orientation before insertion. Flat edge of EPROM to the flat edge of the socket. Re-secure the DC to the front panel. Locate the new EPROM for the PC. Place the PC on an appropriate work surface. Using an appropriate extraction tool, remove the existing EPROM. 1015010 BiPAP Vision Service Manual...
  • Page 187 Set the PC aside for installation later in this procedure. Locate the new EPROM and Alarm B PAL (PAV/T mode only) for the MC. Using an appropriate extraction tool, remove the existing EPROM from U46. 1015010 BiPAP Vision Service Manual...
  • Page 188 Ensure proper orientation before insertion. Flat edge of EPROM to the flat edge of the socket. Step 2 Testing To ensure the integrity of the unit, the Run-In Cycle and the System Final Test found in Chapter 8 must be performed. 1015010 BiPAP Vision Service Manual...
  • Page 189 9.2 BiPAP Vision Oxygen Baffle Installation Instructions (P/N 1004705) Purpose To provide the necessary information to install the Oxygen Baffle into BiPAP Vision units less than serial number 1006001. Oxygen Baffle Description The oxygen baffle provides a better mix of oxygen and air to improve the Air Flow Module (AFM) flow measure- ments.
  • Page 190 Oxygen module outlet tubing support bracket (no longer needed) • “T” tubing (no longer needed) • 22mm coupling at the Oxygen Module outlet (no longer needed) Oxygen tubing support bracket Remove these two screws. Oxygen Module Tubing “T” Connection 22mm Coupler 1015010 BiPAP Vision Service Manual...
  • Page 191 • Place the two nylon washers between the AFM flowbody and the circuit board. • Install the screws and securely tighten. Nylon Washers (2) AFM Mounting Screws (2) New, Final AFM Assembly Nylon Washers (2) 1015010 BiPAP Vision Service Manual...
  • Page 192 NOTE: Make sure that no tubing for the AFM is “kinked” Re-install: • Remaining AFM connections • Oxygen tubing to baffle • Front enclosure • Top enclosure Perform the BiPAP Vision System Final Testing from Chapter 8 of the service manual. 1015010 BiPAP Vision Service Manual...

  • Page 193: Chapter 10: Summary Of Upgrades For Repairs Of Vision Units With Serial Numbers 100500 To 106000

    Summary of upgrades for repairs of Vision units with serial numbers 100500 to 106000 ..............10-2 10.2 Repair Kits No Longer Manufactured ..........10-5 10.3 Installation/Upgrade Instructions for Repair Parts 1004713 and 1000356 for serial number units less than 106001 ......... 10-6 1007914 BiPAP Vision Service Manual...

  • Page 194: Summary Of Upgrades For Repairs Of Vision Units W/ Serial Numbers 100500 To 106000

    PC board and version 12 PAV EPROM DC version 12 PAV EPROM DC ICB connector New ICB cable Revised longer AFM harness Revised longer Power harness PC/MC board spacers Nut for MC center board spacer Pressure tubing 1007914 BiPAP Vision Service Manual...
  • Page 195 DC board and 13 PAV EPROM b) PC board and version 13 PAV EPROM c) MC board and version 13 PAV EPROM d) Revised longer AFM cable e) Power cable, PSS to PC f) Power cable, PC to DC 1007914 BiPAP Vision Service Manual...
  • Page 196 * 5 beep tone sequence for Patient Alarms 3 beep tone sequence for Check Vent Alarms Soft click for an attempt to change a selection that is out of range. Original solid tone for Vent Inop Alarms 1007914 BiPAP Vision Service Manual...

  • Page 197: Repair Kits No Longer Manufactured

    Upgrade kit 1004713 (non Subsystem, PC made this item obsolete. PAV) or 1000356 (PAV) (582146) See Section 10.1 for details. Touchpad, Replaced language specific 1004712, Universal Spanish (582256) items with the international Keypad. French (582257) symbols style. 1007914 BiPAP Vision Service Manual...

  • Page 198: Installation/Upgrade Instructions For Repair Parts

    Additional Items Required: • Ribbon Cable used for testing (RI # 1004699) • BiPAP Vision Service Manual (RI # 582160) • Test Cables (RI # 582161, and 1004823) • Other miscellaneous items as called out in the service manual to support testing after this upgrade is performed as defined in this procedure.
  • Page 199 10. Temporarily install the Ribbon cable, 1004699. This is not part of the kit, but should be kept on hand as part of the service tools needed to repair upgraded BiPAP Vision units s/n<106K. It will be left in only for testing purposes and must be removed afterwards.
  • Page 200 The patient pressure tubing will go from the front enclosure to the middle pressure sensor, port on the right side. 20. Make sure all required connections are correctly made. Just a reminder to double check your work. 1007914 BiPAP Vision Service Manual...
  • Page 201 Note: The PRV muffler DOES NOT get removed once this upgrade is installed into a unit. 24. Perform the Run-In Test and then the System Final Test found in chapter 8 of the BiPAP Vision service manual. 25. When complete, remove the Ribbon (1004699) cable that was temporarily installed into the MC board.

  • Page 202: Appendix A: Tools And Equipment

    Appendix A: Tools and Equipment Appendix A: Tools and Equipment Service Tools and Supplies ............A-2 Acceptable Test Equipment ............A-3 A.3 TSI Inc. Certifier Test System ............ A-6 BiPAP Vision Service Manual 1015010...
  • Page 203 • Test Cable – Respironics P/N 582161 or 1004823 (see test cable description, Chapter 8) • Pressure tubing – 6 in., 6 ft., other misc. lengths as required • Tubing, 6 ft. smooth inner lumen – Respironics P/N 301016, other misc. lengths as required. •...

  • Page 204: Acceptable Test Equipment

    • Any commercially available flowmeter that meets the above specifications A.2.3 Digital Multimeter Specifications: 3 1/2 digit readout Acceptable Options: • Fluke 87 or better model. • Any commercially available digital multimeter that meets the above specifications BiPAP Vision Service Manual 1015010...
  • Page 205 1k H to 100 k H : ± 1 digit 100 k H to 1M H : ± 1 digit Acceptable Options: •Dale model 544L • Any commercially available safety analyzer that meets the above specifications. BiPAP Vision Service Manual 1015010...
  • Page 206 • Certifier Flow Analyzer, RI p/n 1012598 (High flow module) (see A.3 for details) • MSA Mini OX1 (or better) • Servomex 570A Oxygen Analyzer • Any commercially available Oxygen Analyzer that meets the above specifications BiPAP Vision Service Manual 1015010...

  • Page 207: Tsi, Inc. Certifier Test System

    Appendix A: Tools and Equipment A.3. TSI, Inc. Certifier Test System The Certifier FA Test System manufactured by TSI Inc. and will be distributed worldwide by Respironics Inc. This test system, currently being used by the Respironics mobile technicians, is ideal for biomedical testing applications, including ventilators.
  • Page 208 Appendix B: Schematics Schematic Statement ..............B-2 Main Control (MC) ..............B-3 Display Control (DC) ..............B-9 Pressure Control (PC)..............B-20 Air Flow Module (AFM) ............B-25 Oxygen Module (OM) ............... B-26 Power Supply ................B-27 1015010 BiPAP Vision Service Manual...

  • Page 209: Appendix B: Schematics

    Repairs and testing are supported only at the complete board level. Respironics does not recommend component repair of the BiPAP Vision. The circuit boards in the BiPAP Vision are multilayer boards. Due to the very small trace size, extreme care must be used when replacing components to prevent permanent nonrepairable damage to the circuit board.

  • Page 210: Main Control (Mc

    B.2 Main Control (MC) 1015010 BiPAP Vision Service Manual...

  • Page 211: Main Control (Mc

    Appendix B: Schematics B.2 Main Control (MC) BiPAP Vision Service Manual 1015010...
  • Page 212 B.2 Main Control (MC) 1015010 BiPAP Vision Service Manual...
  • Page 213 Appendix B: Schematics B.2 Main Control (MC) BiPAP Vision Service Manual 1015010...
  • Page 214 B.2 Main Control (MC) 1015010 BiPAP Vision Service Manual...
  • Page 215 B.2 Main Control (MC) Appendix B: Schematics BiPAP Vision Service Manual 1015010...
  • Page 216 B.3 Display Control (DC) 1015010 BiPAP Vision Service Manual...

  • Page 217: Display Control (Dc

    B-10 Appendix B: Schematics B.3 Display Control (DC) BiPAP Vision Service Manual 1015010...
  • Page 218 B-11 B.3 Display Control (DC) 1015010 BiPAP Vision Service Manual...
  • Page 219 B-12 Appendix B: Schematics B.3 Display Control (DC) BiPAP Vision Service Manual 1015010...
  • Page 220 B-13 B.3 Display Control (DC) 1015010 BiPAP Vision Service Manual...
  • Page 221 B-14 Appendix B: Schematics B.3 Display Control (DC) 1015010 BiPAP Vision Service Manual...
  • Page 222 B-15 B.4 Display Control (PC)S/N >106K BiPAP Vision Service Manual 1015010...
  • Page 223 B-16 Appendix B: Schematics B.4 Display Control (PC) S/N >106K 1015010 BiPAP Vision Service Manual...
  • Page 224 B-17 B.4 Display Control (PC) S/N >106K BiPAP Vision Service Manual 1015010...
  • Page 225 B-18 B.4 Display Control (PC) S/N >106K Appendix B: Schematics 1015010 BiPAP Vision Service Manual...
  • Page 226 B-19 B.4 Display Control (PC) S/N >106K BiPAP Vision Service Manual 1015010...

  • Page 227: Pressure Control (Pc

    B-20 B.4 Pressure Control Appendix B: Schematics 1015010 BiPAP Vision Service Manual...

  • Page 228: Pressure Control (Pc

    B-21 B.4 Pressure Control BiPAP Vision Service Manual 1015010...
  • Page 229 B-22 Appendix B: Schematics B.4 Pressure Control 1015010 BiPAP Vision Service Manual...
  • Page 230 B-23 B.4 Pressure Control BiPAP Vision Service Manual 1015010...
  • Page 231 B-24 B.4 Pressure Control Appendix B: Schematics 1015010 BiPAP Vision Service Manual...

  • Page 232: Air Flow Module (Afm

    B-25 B.5 Air Flow Module (AFM) BiPAP Vision Service Manual 1015010...

  • Page 233: Oxygen Module (Om

    B-26 B.6 Oxygen Module (OM) Appendix B: Schematics 1015010 BiPAP Vision Service Manual...

  • Page 234: Power Supply

    B-27 B.7 Power Supply BiPAP Vision Service Manual 1015010...
  • Page 235 1015010 DS 06/04/03...

Table of Contents
