Multimedia Expansion Board II (MEB II) User's Guide
FIGURE A-13: ACCELEROMETER
C10
0.1uF
FIGURE A-14: TEMPERATURE SENSOR
+3.3V
C24
0.1uF
GND
DS70005148B-page 42
U9 ADXL325
+3.3V
15
VS
14
VS
7
COM
6
COM
5
COM
3
COM
17
EP
GND
2
ST
U8
1
VDD 2
VOUT
3
GND
MCP9700T-E/TT
12
XOUT AN6/ACCEL_XOUT
C52
47nF
10 GND
YOUT AN7/ACCEL_YOUT
C53
47nF
8 GND
ZOUT AN8/ACCEL_ZOUT
C54
47nF
GND
R34
AN23/TEMP_SENSE
120R
C25
0.1uF
GND
