Appendix B. Bill Of Materials - Microchip Technology Multimedia Expansion Board II User Manual

TABLE B-1: MULTIMEDIA EXPANSION BOARD II (MEB II) BILL OF MATERIALS
Qty. Reference
27 C1, C2, C3, Cap, Ceramic, 0.1 µF, 50V X7R
C4, C5, C6,
C7, C8, C9,
C10, C11,
C12, C13,
C14, C15,
C16, C17,
C18, C19,
C20, C21,
C22, C23,
C24, C25,
C26, C27
2 C30, C31 Cap, Ceramic, 0.01 µF 50V X7R
5 C34, C35, Cap, Ceramic, 1 µF 16V X5R
C36, C37,
C38
11 C39, C40, Cap, Ceramic, 2.2 µF 10V 20% X5R 0603
C41, C42,
C43, C44,
C45, C46,
C47, C48,
C49
2 C50, C51 Cap, Ceramic, 0.22 µF 16V Y5V 0603
3 C52, C53, Cap, Ceramic, 0.047 µF 50V 10% X7R 0603
C54
1 C55 Cap, Ceramic, 0.022 µF 50V 20% X7R 0603
10 C56, C57, Cap, Ceramic, 10 µF 16V X5R
C58, C59,
C60, C61,
C62, C63,
C64, C65
2 C66, C67 Cap, Ceramic, 22 µF 16V 10% X5R 0805
2 C68, C69 Cap, Tantalum, 47 µF 6.3V 20% 1206
5 R1, R2, R3, Resistor, 0.0 Ohm 1/10W 0603 SMD
R4, R5
6 R6, R7, R8, Resistor, 470 Ohm 1/10W 1% 0603 SMD
R9, R10, R11
5 R12, R13, Resistor, 4.70K Ohm 1/10W 1% 0603 SMD
R14, R15,
R16
8 R17, R18, Resistor, 10K Ohm 1/10W 1% 0603 SMD
R19, R20,
R21, R22,
R44, R45
6 R23, R24, Resistor, 1.10K Ohm 1/10W 1% 0603 SMD
R25, R26,
R37, R38
2 R27, R28 Resistor, TF 6.8 Ohm 1% 0.1W 0603
2 R29, R30 Resistor, 100 Ohm 1/10W 1%
1 R31 Resistor, 2.20K Ohm 1/10W 1% 0603 SMD
1 R32 Resistor, 470K 1/10W 1%
1 R33 Resistor, TF 348K Ohm 1% 0.1W 0603
1 R34 Resistor, 120 Ohm, 1/10W 1%
1 R36 Resistor, 100K Ohm 1/10W 1% 0603 SMD
© 2013-2014 Microchip Technology Inc.
MULTIMEDIA EXPANSION BOARD II

Appendix B. Bill of Materials

Description
(MEB II) USER'S GUIDE
Manufacturer
TDK Corporation
TDK Corporation
TDK Corporation
TDK Corporation
Murata Electronics North America
TDK Corporation
Murata Electronics North America
Taiyo Yuden
TDK Corporation
Kemet
Rohm Semiconductor
Rohm Semiconductor
Panasonic - ECG
Stackpole Electronics Inc.
Panasonic Electronic Components
Stackpole Electronics Inc.
Yageo
Rohm Semiconductor
Panasonic - ECG
Stackpole Electronics Inc.
Stackpole Electronics Inc.
Stackpole Electronics Inc.
Part No.
C1608X7R1H104M
C1608X7R1H103M
C1608X5R1C105K
C1608X5R1A225M/0.80
GRM188F51C224ZA01D
C1608X7R1H473K080AA
GRM188R71H223MA01D
EMK212BJ106MG-T
C2012X5R1C226K
T494A476M006AT
MCR03EZPJ000
MCR03EZPFX4700
ERJ-3EKF4701V
RMCF0603FT10K0
ERJ-3EKF1101V
RMCF0603FT6R80
RC0603FR-07100RL
MCR03EZPFX2201
ERJ-3EKF4703V
RMCF0603FT348K
RMCF0603FT120R
RMCF0603FT100K
DS70005148B-page 49
