2.1.3
The MEB II supports display on a separate daughter card through a 60-pin Hirose DF12
board-to-board display connector, as shown in
FIGURE 2-3:
When connecting the Multimedia Expansion Board II (MEB II) to a starter kit or to the
display daughter board, do not have power applied through either the starter kit or the
DC power supply. Failure to heed this caution could result in hardware damage.
The MEB II supports a variety of displays through the daughter board and the kit
includes a 4.3" WQVGA Projected Capacitive (PCAP) Touch display. Refer to
2.1.15 "4.3" WQVGA PCAP Touch Display Daughter Board"
Table 2-2
© 2013-2014 Microchip Technology Inc.
Display Connector
DISPLAY CONNECTOR
shows the display connector functional mapping.
Figure 2-3.
CAUTION
Hardware
for additional details.
