Appendix A. Board Layout and Schematics
This appendix provides examples of the board layout and component schematics for
the Multimedia Expansion Board II (MEB II) and includes the following figures:
•
Figure A-1: "MEB II Layout (Top Assembly)"
•
Figure A-2: "MEB II Layout (Bottom Assembly)"
•
Figure A-3: "4.3" WQVGA PCAP Touch Board Layout (Top Assembly)"
•
Figure A-4: "4.3" WQVGA PCAP Touch Board Layout (bottom Assembly)"
•
Figure A-5: "Power Supply"
•
Figure A-6: "Starter Kit Connector"
•
Figure A-7: "Display connector"
•
Figure A-8: "EBI SRAM Memory"
•
Figure A-9: "VGA Camera Sensor and 2.8V Regulator"
•
Figure A-10: "24-bit Audio Codec"
•
Figure A-11: "Bluetooth
•
Figure A-12: "802.11b/g Transceiver"
•
Figure A-13: "Accelerometer"
•
Figure A-14: "Temperature Sensor"
•
Figure A-15: "microSD Card Slot"
•
Figure A-16: "Touch Buttons"
•
Figure A-17: "PICtail™ Connector"
•
Figure A-18: "Push Button and User Controlled LEDs"
•
Figure A-19: "Display Panel Connector and Backlight Circuit"
•
Figure A-20: "Touch Controller"
