Multimedia Expansion Board II (MEB II) User's Guide
TABLE B-1: MULTIMEDIA EXPANSION BOARD II (MEB II) BILL OF MATERIALS (CONTINUED)
Qty. Reference
5 R39, R40, Resistor, 150 OHM 1/10W 1% 0603 SMD
R41, R42,
R43
1 D1 DIODE SCHOTTKY 1A 100V SMA
1 D2 LED, SMD, GRN, 0603 package
5 D3, D4, D5, LED, SMD, RED, 0603 package
D6, D7
1 J1 Hirose FX10_ 168-pin Receptacle/ESK MH
1 J2 Connector, FEMALE 28 POS DL .1" R/A TIN
1 J3 Connector, POWER JACK 2.5 X 5.5 MM HI CUR
1 J4 Connector, HDR 60 POS 0.5 MM SMD GOLD
3 J5, J6, J7 Connector, JACK STEREO 5 POS 3.5 MM SMD
1 J8 Connector, Mini microSD 8-PIN PCB GOLD
1 J9 Connector, HEADER 3 POS .100 RT/A SMD
1 J10 Connector, MOD JACK R/A 6P6C SMD
1 L1 4.7 µH 20%
3 L2, L3, L4 INDUCTOR MULTILAYER 3300 NH 0603
4 FB1, FB2, FERRITE CHIP 600 OHM 500 MA 0805
FB3, FB4
1 U1 CODEC (24-bit Stereo)
1 U2 Dual-mode Bluetooth HCI
1 U3 TX RX RF 2.4 GHz PCB ANT 802.11b
1 U4 IC REG BUCK SYNC 5V 2A 16-VQFN
1 U5 IC LDO REG 1000 mA 3.3V SOT223-3
1 U6 SENSOR CAMERA CMOS 20 CAMERACUBE
1 U7 IC REG LDO ADJ 50 mA SOT23A-5
1 U8 LP Linear Active Thermistor SOT-23-3
1 U9 Accelerometer ADXL325
1 U10 LDO Voltage Regulator 1.8V 250 mA
1 U11 SRAM 16M (1M x 16) 10 ns Async SRAM
1 S1 SWITCH TACTILE SPST-NO 0.05A 12V
1 GND TP-115 * 50_SMT
TABLE B-2: DISPLAY BOARD BILL OF MATERIALS
Qty. Reference
1 4.3" Display 4.3" Display w/ TP
3 C1, C2, C7 Cap, Ceramic, 10 µF 16V X5R
1 C3 Cap, Ceramic, 10 µF 35V 10% X5R 1206
3 C4, C5, C6 Cap, Ceramic, .10 µF 50V X7R 0603
1 D1 Diode, Schottky, 30V 100 mA SOD323
1 J1 Connector, RCPT 60 POS 0.5 mm SMD GOLD
1 J2 Connector, FPC 40 POS 0.5 mm PITCH SMD
1 J4 Connector, FPC 30 POS 0.5 mm PITCH SMD
1 L1 15 µH ±20%
1 Q1 MOSFET N-CH 30V 2A SOT23
1 R1 Resistor, .50 Ohm 1/3W 1% 0805 SMD
1 R2 Resistor, 7.68K Ohm 1/10W 1% 0603 SMD
1 R3 Resistor, 10K Ohm 1/10W 1% 0603 SMD
1 R4 Resistor, 470 Ohm 1/10W 1% 0603 SMD
1 U1 MCP1650-E/MS_BOOST
1 U2 MTCH6301
1 J3 Connector, FFC 6 POS 1 mm R/A ZIF SMD
DS70005148B-page 50
Description
TE
Micro Commercial Co.
Kingbright Corp.
Kingbright Corp.
Hirose Electric Co. Ltd.
Sullins Connector Solutions
CUI Inc.
Hirose Electric Co. Ltd.
Switchcraft Inc.
Amphenol
Sullins Connector Solutions
Amphenol
CoilCraft
Abracon Corporation
TDK Corporation
AKM
Flaircomm
Microchip Technology Inc.
Microchip Technology Inc.
Microchip Technology Inc.
OmniVision Technologies Inc
Microchip Technology Inc.
Microchip Technology Inc.
Analog Devices Inc
Microchip Technology Inc.
Integrated Silicon Solution Inc.
C&K Components
Keystone Electronics
Description
AMTouch USA
Taiyo Yuden
Taiyo Yuden
TDK Corporation
Diodes Inc.
Hirose Electric Co. Ltd.
Omron Electronics Inc., EMC Div
Omron Electronics Inc., EMC Div
CoilCraft
Alpha & Omega Semiconductor Inc.
Susumu
Panasonic - ECG
Stackpole Electronics Inc.
Rohm Semiconductor
Microchip Technology Inc.
Microchip Technology Inc.
Molex Connector Corporation
Manufacturer
3-1676481-5
SS110-TP
APT1608SGC
APT1608EC
FX10A-168S-SV
PPTC142LJBN-RC
PJ-002BH-SMT
DF12(3.0)-60DP-0.5V(86)
35RASMT4BHNTRX
101-00581-59
GBC03SBSN-M89
RJLSE6202101T
LPS4018-472M
AIML-0603-3R3K-T
MMZ2012Y601B
AK4953A
FLC_BTM805
MRF24WG0MA-I/RM
MCP16322T-500E/NG
MCP1826S-3302E/DB
OVM7690-R20A
TC1071VCT713
MCP9700T-E/TT
ADXL325BCPZ-RL7
MCP1700T-1802E/TT
IS61WV102416BLL-10TLI
PTS635SK25SMTR LFS
5015
Manufacturer
P3003-02-1-01 Touch
Panel/LCD assembly
EMK212BJ106MG-T
GMK316BJ106KL-T
C1608X7R1H104M
SD107WS-7-F
DF12(30)-60DS-0.5V(86)
XF2M-4015-1A
XF2M-3015-1A
LPS3015-153ML
AO3424
RL1220S-R50-F
ERJ-3EKF7681V
RMCF0603FT10K0
MCR03EZPFX4700
MCP1650S-E/MS
MTCH6301-I/PT
52271-0679
© 2013-2014 Microchip Technology Inc.
Part No.
Part No.
