Multimedia Expansion Board II (MEB II) User's Guide
The bottom side of the 4.3" WQVGA PCAP touch display board includes these key
features, as shown in
1. 60-pin MEB II connector.
2. Display panel connector.
3. PCAP touch connector.
4. Microchip touch controller (MTCH6301).
5. 6-in PCAP touch connector for future use.
6. PICkit™ Serial Analyzer interface (optional)
FIGURE 1-5: WQVGA PCAP TOUCH DISPLAY BOARD LAYOUT (BOTTOM VIEW)
6
DS70005148B-page 16
Figure 1-5:
4
3
1
5
2
