Microchip Technology Multimedia Expansion Board II User Manual page 21

TABLE 2-1: STARTER KIT CONNECTOR MAPPING (CONTINUED)
Starter Kit Connector
Pin
Signal
Number
138 EBID1
139 EBID12
140 EBID0
141 EBID13
142 EBID4
143 EBID14
144 LCD_B1
145 LCD_R7
146 LCD_B0
147 EBID10
148 LCD_G7
149 LCD_G1
150 EBID9
151 EBID5
152 EBID8
153 EBID6
154 EBID7
155 EBIOE
13 MCLR
110 RH10
124 SCL1
126 SDA1
92 AN42
111 AN28
80 RJ7
86 RA9
90 OC5
104 SDA3
106 SCL3
19 INT2
93 RE8
27 EBIA1/RK1
31 EBIA3/RK2
61 EBIA16/RK0
63 EBIA17/RK3
65 EBIA18/RK4
67 EBIA19/RK5
73 EBIA20/RK6
75 EBIA21/RK7
© 2013-2014 Microchip Technology Inc.
Pin
Component
Type
I/O EBI-SRAM/Display
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
O
I/O Touch
O
I/O
I/O
I mTouch button
I
O VGA Camera
I
O
I/O
I/O
I
O VGA Camera
Regulator
I/O EBI-SRAM/
VGA Camera
I/O
I/O
I/O
I/O
I/O
I/O
I/O
MEB II
Description
B4
R4
B3
R5
B2
R6
B1
R7
B0
G0
G7
G1
G6
G2
G5
G3
G4
Pixel Clock
Touch Controller Reset (System Reset in general)
Touch Wake-up
Serial Clock
Serial Data
Touch Button B1
Touch Button B2
Power Down
Vertical Sync
System Input Clock
Serial Data
Serial Clock
VGA Camera Pixel
Shutdown
Address 1/VGA Camera Data 1
Address 3/VGA Camera Data 2
Address 16/VGA Camera Data 0
Address 17/VGA Camera Data 3
Address 17/VGA Camera Data 4
Address 17/VGA Camera Data 5
Address 17/VGA Camera Data 6
Address 17/VGA Camera Data 7
Hardware
DS70005148B-page 21
