Chapter 2: Jumpers and Connectors
USB Connector
Connector type: 10-1-pin header, 2.54mm pitch
Connector location: USB2
2
10
1
9
Pin
Definition
1
+5V_USB2_78
3
USB2N_5
5
USB2P_5
7
GND
9
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
+5V_USB2_78
4
USB2N_6
6
USB2P_6
8
GND
10
NC
USB Connector
Connector type: 10-1-pin header, 2.54mm pitch
Connector location: USB3
2
10
1
9
Pin
Definition
1
+5V_USB2_34
3
USB2N_9
5
USB2P_9
7
GND
9
12
Pin
Definition
2
+5V_USB2_34
4
USB2N_3
6
USB2P_3
8
GND
10
NC
PEAK 980 User Manual
