Figure 5-19 Installing the Charging Modules (for MaxiCharger DC 240)
Table 5-8 Charging Module Installation Specifications (for MaxiCharger DC 240)
Type
MaxiCharger DC 160
(EF160A3001)
MaxiCharger DC 180
(EF180A3001)
MaxiCharger DC 200
(EF200A3001)
MaxiCharger DC 220
(EF220A3001)
MaxiCharger DC 240
(EF240A3001)
Rated Power
160 kW
180 kW
200 kW
220 kW
240 kW
Number of
Location
Modules
8 PCS
1, 2, 3, 4, 7, 8, 9, 10
9 PCS
1, 2, 3, 4, 5, 7, 8, 9, 10
1, 2, 3, 4, 5, 7, 8, 9, 10,
10 PCS
11
1, 2, 3, 4, 5, 6, 7, 8, 9,
11 PCS
10, 11
1, 2, 3, 4, 5, 6, 7, 8, 9,
12 PCS
10, 11, 12
42
