Parts List - Analog Devices DC2629A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 4 C2, C3, C5, C6
2 1 C4
3 1 C9
4 1 C11
5 2 C13, C14
6 1 L1
7 1 R9
8 1 R10
9 1 R12
10 1 U1
Additional Demo Board Circuit Components
1 2 C1, C18
2 2 C7, C15
3 1 C8
4 2 C16, C17
5 2 C19, C20
6 1 L2
7 1 Q1
8 1 R1
9 1 R2
10 2 R3, R11
11 2 R4, R13
12 1 R8
13 1 R14
14 1 R15
Hardware: For Demo Board Only
1 10 E1-E3, E5, E12, E14-E17, E20 TEST POINT, TURRET, 0.064", MTG. HOLE
2 6 E4, E7, E10, E13, E18, E21
3 5 E6, E8, E9, E11, E19
4 1 JP1
5 4 MP1-MP4
6 1 XJP1
Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications
subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
DEMO MANUAL DC2629A
PART DESCRIPTION
CAP ., 22uF , X5R, 25V, 20%, 0805
CAP ., 15pF, C0G, 50V, 5%, 0402
CAP ., 0.033uF , X7R, 25V, 10%, 0402
CAP ., 220pF, X7R, 50V, 10%, 0402
CAP ., 10uF , X5R, 10V, 20%, 0603
IND., 0.10uH 20% SHEILDED POWER INDUCTOR
RES., 140k OHMS, 1%, 1/16W, 0402, AEC-Q200
RES., 100k OHMS, 1%, 1/16W, 0402, AEC-Q200
RES., 10k OHMS, 1%, 1/10W, 0402, AEC-Q200
IC, Low Voltage Syn. Stepdown Reg., LQFN-18
CAP ., 470uF , TANT. POSCAP , 6.3V, 20%, 7343,
18mOHMS, TPE
CAP ., 0.1uF , X5R, 25V, 10%, 0402
CAP ., 22uF , X5R, 25V, 20%, 0805
CAP ., 10uF , X5R, 10V, 20%, 0603
CAP ., 0.22uF , X7R, 16V, 10%, 0402, AEC-Q200
IND., 100 OHMS @ 100MHz, FERRITE BEAD, 25%,
8A, 6mOHMS, 1812
XSTR., MOSFET, N-CH, 40V, TO-252 (DPAK)
RES., 1M OHMS, 1%, 1/16W, 0402, AEC-Q200
RES., 249k OHMS, 1%, 1/16W, 0402
RES., 100k OHMS, 5%, 1/16W, 0402, AEC-Q200
RES., 0 OHM, 1/16W, 0402, AEC-Q200
RES., 20 OHMS, 1%, 1/16W, 0402, AEC-Q200
RES 0.1 OHM 1% 10W 2818
RES., 10k OHMS, 5%, 1/16W, 0402, AEC-Q200
TEST POINT, TURRET, 0.094", MTG. HOLE
CONN., BANANA JACK, FEMALE, THT, NON-
INSULATED, SWAGE
CONN., HDR, MALE, 1x3, 2mm, VERT, STR, THT
STANDOFF , NYLON, SNAP-ON, 0.50"
CONN., SHUNT, FEMALE, 2 POS, 2mm
MANUFACTURER/PART NUMBER
SAMSUNG, CL21A226MAQNNNE
KEMET, C0402C150J5GAC7867
KEMET, C0402C333K3RACTU
YAGEO, CC0402KRX7R9BB221
AVX, 0603ZD106MAT2A
COILCRAFT, XEL4030-101MEC
VISHAY, CRCW0402140KFKED
VISHAY, CRCW0402100KFKED
PANASONIC, ERJ2RKF1002X
ANALOG DEVICES, LTC3310SEV#PBF
PANASONIC, 6TPE470MI
AVX, 04023D104KAT2A
SAMSUNG, CL21A226MAQNNNE
AVX, 0603ZD106MAT2A
MURATA, GCM155R71C224KE02D
WURTH ELEKTRONIK, 74279226101
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW04021M00FKED
VISHAY, CRCW0402249KFKED
VISHAY, CRCW0402100KJNED
VISHAY, CRCW04020000Z0ED
VISHAY, CRCW040220R0FKED
VISHAY DALE, WSHP2818R1000FEA
VISHAY, CRCW040210K0JNED
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8833
WURTH ELEKTRONIK, 60800213421
Rev. 0
9
