QUICK START PROCEDURE
V
SG_INPUT
2V/DIV
0V
V
I_STEP
200mV/DIV
200mV
1.20V
V
OUT
20mV/DIV
LTC3310S DC2629A TRANSIENT
V = 3.3V
IN
V = 1.2V
OUT
I = 2A TO 8A
OUT
6
Figure 3. Technique for Measuring Load Step Response
20 s/DIV
