ESC BUTTON – cancels a selection (or action) from a menu or
7)
returns to the previous screen.
LEFT SCROLL BUTTON – when look up DTC definitions, moves to
8)
previous character and views additional information on previous screens
if DTC definition covers more than one screen; deselect all marked PID
data when viewing or recording customized live data list; views previous
frames of recorded data when playing back live data. It is also used to
update DTC library when pressed.
UP SCROLL BUTTON – moves up through menu and submenu
9)
items in menu mode. When more than one screen of data is retrieved,
moves up through the current screen to the previous screens for
additional data.
RIGHT SCROLL BUTTON – when look up DTC definitions, moves
10)
to next character and view additional information on next screens if DTC
definition covers more than one screen; selects/deselects PID data when
viewing or recording customized live data list, and views next frames of
data when playing back live data.
OK BUTTON – confirms a selection (or action) from a menu.
11)
DOWN SCROLL BUTTON – moves down through menu and
12)
submenu items in menu mode. When more than one screen of data is
retrieved, moves down through the current screen to next screens for
additional data.
13) OBD II CONNECTOR – connects the scan tool to the vehicle's Data Link
Connector (DLC).
14) USB CONNECTOR – connects the scan tool to the PC for printing and
upgrading.

Specifications

Item
Display
Connectivity
Operating Temp.
Table 2-1 Specifications
Description
2.8-inch LCD (320x240 dpi)
USB mini 2.0
OBD II DB15
0℃ to 60 ℃ (32℉ to 140℉)
4
