System Setup - Autel AUTOLINK AL529 Manual


If retrieved DTCs contain any manufacturer specific codes, the
AutoVIN function embedded in this tool will automatically display the
definition of the code.
 If definition could not be found, the scan tool displays "Please refer
to vehicle service manual!"
 For code breaker information, you need to press the "?" Help button.
In the Code Breaker screen, there are three options to assist user to
understand DTC more: System Description and Quick Check to read
detailed description of DTCs, General Notes to view helpful repair
information of DTCs.
4) To view previous or next DTC in the built-in DTC library, use the
LEFT/RIGHT button.
5) To enter another DTC, press the ESC button to return to previous screen.
6) To exit to Main Screen, press the ESC button.

System Setup

The scan tool allows you to make the following adjustments and settings:
1) Language: Selects the desired language.
2) Configure Monitors: Sets the monitors you want to test.
3) Unit of measure: Sets the unit of measure to English or Metric.
4) Key Beep Set: Turns on/off beep.
5) Status Beep Set: Turns on/off the I/M Readiness Status beep.
6) Tool Self-test: Checks if the LCD display, LED lamps and keyboard are
working normally.
7) Update Mode: Accesses the Update Mode.
8) Vehicle Info Show Set: Turn on/off the Vehicle Info display.

Settings of the unit will remain until change to the existing settings is
made.
7
