Item
Storage Temp.
External Power
Dimensions (LxWxH)
Weight
Accessories Included
User Manual – instructions on tool operations.
1)
Quick Guide – instructions on tool registration and update.
2)
OBD II Cable – provides power to tool and communicates between tool
3)
and vehicle.
USB Cable – used to upgrade the scan tool, and to print retrieved data.
4)
Navigation Characters
Characters used to help navigate the scan tool are:
$ – identifies the control module number from which data is retrieved.
1)
Indicates the Test ID in On-Board Mon. Test.
? – indicates help or code breaker information is available.
2)
G – indicates graphic viewing is available.
3)
Keyboard
No solvents such as alcohol are allowed to clean the keypad or display. Use
a mild nonabrasive detergent and a soft cotton cloth. Do not soak the keypad
as the keypad is not waterproof.
Power
The scan tool is powered via the vehicle Data Link Connector (DLC). Follow
the steps below to turn on the scan tool:
Description
-20℃ to 70 ℃ (-1℉ to 158℉)
8.0 to 18.0V power provided via vehicle
battery
183 mm (7.2") x 91 mm (3.58") x 33 mm (1.3")
237 g (0.522 lb.)
5
