2) Observe on-screen instructions. Press the OK button to continue; press
the ESC button, or use LEFT/RIGHT button to select NO and press the
OK button to return to Record Data menu.
3) Use the RIGHT button select/deselect data parameters. Selected
parameters are marked with solid squares. Press the OK button to
confirm.

If you wish to deselect all marked items, press LEFT button.

A message comes up to ask for your confirmation.

If you decide to deselect these items, press OK; if you decide not
to, press the ESC button, or use the UP/DOWN button to select NO
and press OK to continue PID selections.
4) Use the UP/DOWN scroll button to select a trigger mode and press the
OK button.

If data from previously tested vehicle is not erased, data from
current test will be stored in temporary cache.
5) Use the UP/DOWN scroll button to select a memory location and press
the OK button.
6) Observe on-screen instructions to select DTC trigger mode.
7) Wait for DTC to trigger recording or press OK to start recording.
8) The scan tool keep recording PID data until user presses ESC button,
the selected memory location is full, or it completes recording. A
message prompting to playback data shows on the screen.

If you wish to playback recorded data, press the OK button; if you
do not wish to playback, press the ECS button, or use the
LEFT/RIGHT button to select NO and press the OK button to return
to Record Data menu.
Playback Data
The Playback Data function allows viewing of previously stored PID data.
1) To playback recorded data, use the UP/DOWN scroll button to select
Playback Data from Live Data menu and press the OK button.

You are also allowed to playback recorded data immediately after
recording.
37
