Figure 4-15 Sample Custom Data Set Screen 3
5) Use the ESC button to return to previous menu.
Record Data
The Record Data function allows recording vehicle modules' Parameter
Identification (PID) data to help diagnose intermittent vehicle problems. A
recording includes 5 frames of live data before trigger event and several
frames after trigger event.
There are two trigger modes used to record data:
A. Manual Trigger – allows user to press the OK button to start recording.
B. DTC Trigger – automatically records PID data when a fault that causes
a DTC to set is detected by vehicle.
NOTE
DO NOT try to drive and operate the scan tool at the same time! Always
have another person operate the scan tool while driving.
To record live data, use the UP/DOWN scroll button to select Record Data
from Live Data menu and press the OK button.
Record Complete Data Set
1) To record complete set of live data, use the UP/DOWN scroll button to
select Complete Data Set from Record Data menu and press the OK
button.
