recording customized live data list, and views next frames of
data when playing back live data.
13)
menu and submenu items in menu mode. When more than one
screen of data is retrieved, moves down through the current
screen to next screens for additional data.
14) USB CONNECTOR – Connects the scan tool to the PC for
printing and upgrading.

3.2 Specifications

1) Display: TFT color display (320 x 240 dpi)
2) Operating Temperature: 0 to 60° C (32 to 140 F° )
3) Storage Temperature: -20 to 70° C (-4 to 158 F° )
4) External Power: 8.0 to 18.0 V power provided via vehicle
battery
5) Dimensions:
199 mm (7.83")
6) Weight: 0.28kg(without wire) 0.484kg(with wire)

3.3 Accessories Included

User's Manual -- Instructions on tool operations.
1)
CD -- Includes user‟s manual, MaxiLink update software, and
2)
etc.
3) OBD2 cable -- Provides power to tool and communicates
between tool and vehicle.
4) USB cable -- Used to upgrade the scan tool, and to print
retrieved data.
5) Carry case -- A nylon case to store the scan tool when not in use.

3.4 Navigation Characters

Characters used to help navigate the scan tool are:
DOWN SCROLL BUTTON – Moves down through
Length Width
104.5 mm (4.11")
12
Height
37.5 mm (1.48")
