2) Use the UP/DOWN button to select the memory location marked with
an asterisk (*) icon.
Figure 4-24 Sample Select Memory Screen 2
 If there is no recording in selected location, a message "Not
Supported or Stored No Data" displays on the screen.
3) Use the UP/DOWN button to view recorded PIDs of each frame.
Figure 4-25 Sample Playback Data Screen
4) Use the LEFT/RIGHT button to view PIDs of next or previous frames.

View Freeze Frame Data

Freeze Frame Data allows the technician to view the vehicle's operating
parameters at the moment a DTC (Diagnostic Trouble Code) is detected.
For example, the parameters may include engine speed (RPM), engine
coolant temperature (ECT), or vehicle speed sensor (VSS) etc. This
information will aid the technician by allowing the parameters to be
duplicated for diagnostic and repair purposes.
1) To view freeze frame data, use the UP/DOWN scroll button to select
View Freeze Frame from Diagnostic Menu and press the OK button.
38
