LEFT SCROLL BUTTON – When look up DTC
5)
definitions, moves to previous character and views additional
information on previous screens if DTC definition covers more
than one screen; views previous screen or previous frames of
recorded data. It is also used to view previous trouble code
when viewing DTCs.
6)
Breaker function.
7)
menu and submenu items in menu mode. When more than one
screen of data is retrieved, moves down through the current
screen to next screens for additional data. When looking up DTC,
it is used to change value of selected character.
RIGHT SCROLL BUTTON – When look up DTC
8)
definitions, moves to next character and view additional
information on next screens if DTC definition covers more than
one screen; views next screen or next frames of recorded data. It
is also used to view next trouble code when viewing DTCs.
9)
menu.
10)
submenu items in menu mode. When more than one screen of
data is retrieved, moves up through the current screen to the
previous screens for additional data. When looking up DTC, it is
used to change value of selected character.
11) USB CONNECTOR – Connects the scan tool to the PC for
printing.
12) TF CARD SLOT – Holds the TF card.

3.2 Specifications

1) Display: TFT color display (320 x 240 dpi)
2) Operating Temperature: 0 to 60° C (32 to 140 F° )
HELP BUTTON – Provides help information and Code
DOWN SCROLL BUTTON –Moves down through
OK BUTTON – Confirms a selection (or action) from a
UP SCROLL BUTTON – Moves up through menu and
