Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
1 7 19
2 8
20
3 9 21
10 22
11 23
12 24
13 25
14 26
15 27
4 16 28
Main Body
5 17 29
ECU
6 18 30
Refer to the
Optional starter disable
connection section for relay
and connection details.
ENGINE
START
STOP
7 933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Body ECU
(White or Black 30-pin
connector)
(-) Parking Lights: Pin 30
BRX: Pin 4
BTX: Pin 16
(-) Push-To-Start:
Blue or Lt. Green, pin 7
Black
7
connector 6 5 4 3 2 1
14 12 11 10
13 9 8
(black 7-pin connector)
Engine Start Stop Switch
(black conn)
HS CAN High: Red or Violet, pin 6
1 8
9 16
HS CAN Low: White
or Red, pin 14
(+) 12V: Pin 16
HS CAN High: Tan/Black: 2
Immo Data 2: Orange/Black: 7
Immo Data 1: Yellow/Black: 8
(-) Parking Lights Output: Lt. Green/Black: 1
(-) GWA Output: Blue/White: 2
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
Siren
(-) Hood Input: Gray: 21
Hood Pin
(-) Ground: Blue/Red: 2
(-) SLP Output: Blue: 3
(+) 12V Input: Red: 6 & 12
(-) SLP: Green or
Lt. Blue, pin 4
7 6 5 4 3 2 1
Steering Lock
Diagnostic Connector OBDII
(connector side view)
HS CAN Low: Tan: 1
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
Slide to open
(-) Ground: Black: 10
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
).
