Vehicle Connections - Directed DIRECTECHS DS3+ Installation Manual

Vehicle connections

The connection information listed below is specific to the 2015 Toyota Sienna (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low
H1/2 Tan/Black (Data) HS CAN High
H1/3 Orange/Brown No Connection
H1/4 Orange/Green No Connection
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black (Data) Immo Data 2
H1/8 Yellow/Black (Data) Immo Data 1
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Pk Light Output
H2/2 Blue/White (-) Ground When Armed (GWA) Output [2]
H2/3 Dk. Green/Black No Connection
H2/4 Red/White No Connection
H2/5 Brown/Black No Connection
H2/6 Brown/White No Connection
H2/7 White (+) No Connection
H2/8 Violet/Black No Connection
H2/9 Dk. Blue/Black No Connection
H2/10 Lt. Blue/Black (-) PTS Output [3]
H2/11 Brown/Red (+) Siren Output [2]
H2/12 Pink No Connection
H2/13 Violet No Connection
H2/14 Brown No Connection
H2/15 White/Blue No Connection
H2/16 Red/Blue No Connection
9 933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Connects To
Wire Location
OBD-Data Link Connector, white 16 pin plug, pin 14
OBD-Data Link Connector, white 16 pin plug, pin 6
No Connection
No Connection
No Connection
No Connection
Body ECU on dash fuse box, white 30 pin plug, pin 16
Body ECU on dash fuse box, white 30 pin plug, pin 4
Connects To
Wire Location
Body ECU on dash fuse box, white 30 pin plug, pin 30
Starter:
Power Management ECU behind glove box, white 30 pin plug,
pin 3
Ignition:
dash fuse box, white 40 pin plug (2F), pin 6
Must use a relay.
Must use a 1A 1N4002 or larger diode.
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
engine start stop switch, black 14 pin plug, pin 7
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
data white Mandatory
data red Mandatory
data blue (BTX) Remote Start
Only
data black (BRX) Remote Start
Only
(+/-) Wire Color Connection
- yellow Mandatory
+ pink Security Only
+ red
- blue Remote Start
Only
Security Only
