Directed DIRECTECHS DS3+ Installation Manual page 10

Module
Conn./Pin Color Description
H2/17 Black/White No Connection
H2/18 Orange/Black No Connection
H2/19 Blue No Connection
H2/20 Green No Connection
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White No Connection
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. No Connection
H3/2 Blue/Red Relay N.O. (-) Ground
H3/3 Blue Relay COM (-) SLP Output
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM No Connection
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. No Connection
H3/8 Lt. Green Relay COM No Connection
H3/9 Lt. Green/White Relay N.C. No Connection
H3/10 Black (-) Ground
H3/11 White Relay COM No Connection
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black No Connection
H4/3 Pink/Black No Connection
H4/4 Pink/White No Connection
H4/5 Red No Connection
H4/6 Green No Connection
H4/7 Violet No Connection
H4/8 Orange No Connection
H4/9 Red/White No Connection
H4/10 Pink No Connection
10 933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
steering lock actuator on steering column, black 7 pin plug, pin
4
No Connection
No Connection
OBD-Data Link Connector, white 16 pin plug, pin 16
No Connection
No Connection
No Connection
No Connection
OBD-Data Link Connector, white 16 pin plug, pin 16
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
(chassis ground) Remote Start
Only
- green Remote Start
Only
+ black (7.5A) Mandatory
(chassis ground) Mandatory
+ black (7.5A) Mandatory
(+/-) Wire Color Connection
