Introduction

DS3+ is a complete solution for remote start, security (when security features are enabled) and bypass. This guide provides
information on the installation of the module as a digital solution. Please refer to www.directechs.com for more information about
which configuration is best for your application.
Warning! This module can be configured using the web tool located at www.directechs.com. The DS3/DS3+ module is not
equipped with Bluetooth, therefore the blue LED will not flash during module programming or when performing a soft or hard reset.
DS4+ is a complete solution for remote start, security (when security features are enabled), bypass, and features
built in Bluetooth 4.0 allowing you to configure and control your system. This guide provides information on the
installation of the module as a digital solution. Please refer to the DirectLink application or www.directechs.com
for more information about which configuration is best for your application.
Warning! This module is designed to be configured using the DirectLink application for mobile devices,
however it can also be configured using the web tool located at www.directechs.com. To download the DirectLink mobile
application, please visit the Google Play or Apple store.

Vehicle function compatibilities

This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Auto Headlamp Shutoff
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Sliding Door Control Driver
Sliding Door Control Passenger
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
* Fuel Level
* Odometer
Immobilizer Bypass-Data No Key Req'd
3x LOCK START (Start control using OEM Remote)
3
933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Ignition Activation
SmartStart
Start (Crank) Activation
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
E-Brake Status
Ignition Status
