Removing The Access Point - Ruijie RG-AP850-I-V2 Series Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
Before mounting the AP on the bracket, you must first install the Ethernet cables.

3.6 Removing the Access Point

1. If the hidden lock is enabled, attach the front part of the key to the edge of the mounting bracket (keep the Ruijie key
logo facing the top panel of the AP). Slide the key along with the four edges of the mounting bracket, and attempt to
insert the key into the keyhole. It can only be inserted into one marked keyhole.
Figure 3-9 Inserting the Key for Unlocking
2. If the AP is installed on the wall, hold the AP in your hands and push it upward and away from the bracket in the LAN
port direction.
Figure 3-10 Removing the Wall Mount AP
3. If the AP is installed on the ceiling, hold the AP in your hands and slide it sideways. Attempt to slide it in four
directions (the AP can only slide out in one direction).
Figure 3-11 Removing the Ceiling Mount AP
Installing the Access Point
·
