1 Product Overview

The RG-AP850-I(V2) AP, supporting 802.11ax, features a tri-radio, dual-band design. The three radios deliver up to
1,150Mbps + 4.8Gbps + 867Mbps access rates. It supports security, radio frequency (RF) control, mobile access, Quality
of Service (QoS) and seamless roaming. In coordination with the Ruijie RG-WS Wireless Controller Series, this product
can easily deliver wireless data forwarding, high performance security, and access control.
The RG-AP850-I(V2) AP can concurrently operate in 802.11ax, 802.11ac Wave2, 802.11ac Wave1 and 802.11n modes.
And it is downward compatible with 802.11a/b/g/n.
In addition, the AP can be mounted on a ceiling or wall. The product supports both local power supply and PoE to adapt to
challenges in a wide variety of deployment scenarios, including large-scaled campuses, enterprises, and WiFi hotspots.

1.1 Technical Specifications

Table 1-1 RG-AP850-I(V2) Technical Specifications
Model
RF
Transmission
Protocol
Operating Bands
Antenna
Spatial Streams
Max Throughput
Modulation
Receive Sensitivity
RG-AP850-I(V2)
2.4G: 4×4 MU-MIMO
5.2G: 4×4 MU-MIMO
5.8G: 2×2 MIMO
Tri-radio and dual-band frequency cards support concurrent 802.11ax and 802.11a/b/g/n/ac.
5725MHz to 5850MHz (a/n/ac VHT80）
5150MHz to 5350MHz (a/n/ac/ax HE160)
2400MHz to 2483.5MHz (b/g/n/ax, HE40)
Built-in omni-directional antenna
2.4G: 4 streams
5.2G: 4 streams
5.8G: 2 streams
2.4G: up to 1,150 Mbps
5.2G: up to 4.8 Gbps
5.8G: up to 867 Mbps
Up to 6.82 Gbps per AP
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16-QAM@24 Mbps, 64-QAM@48/54 Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM and1024QAM
OFDMA
11b: –96 dBm(1 Mbps), –93 dBm(5 Mbps), –89 dBm(11 Mbps)
11a/g: –91 dBm (6 Mbps), –85 dBm (24 Mbps), –80 dBm (36 Mbps), –74 dBm (54 Mbps)
11n: –90 dBm@MCS0, –70 dBm@MCS7, –89 dBm@MCS8, –68 dBm@MCS15
11ac: HT20: –88 dBm (MCS0), –63 dBm (MCS9)
11ac: HT40: –85 dBm (MCS0), –60 dBm (MCS9)
11ac: HT80: –82 dBm (MCS0), –57 dBm (MCS9)
