miniLAB 1008 User's Guide

4-channel differential mode

Pin Signal Name
1 CH0 IN HI
2 CH0 IN LO
3 GND
4 CH1 IN HI
5 CH1 IN LO
6 GND
7 CH2 IN HI
8 CH2 IN LO
9 GND
10 CH3 IN HI
11 CH3 IN LO
12 GND
13 PC +5 V
14 PC +5 V
15 CAL

8-channel single-ended mode

Pin Signal Name
1 CH0 IN
2 CH1 IN
3 GND
4 CH2 IN
5 CH3 IN
6 GND
7 CH4 IN
8 CH5 IN
9 GND
10 CH6 IN
11 CH7 IN
12 GND
13 PC +5 V
14 PC +5 V
15 CAL

DB37 connector and pin out

Connector type
Compatible cables
Compatible accessory products
Pin Signal Name
16 DIO0
17 DIO1
18 GND
19 DIO2
20 DIO3
21 GND
22 D/A OUT 0
23 D/A OUT 1
24 GND
25 CTR
26 GND
27 GND
28 PC +5 V
29 PC +5 V
30 TST
Pin Signal Name
16 DIO0
17 DIO1
18 GND
19 DIO2
20 DIO3
21 GND
22 D/A OUT 0
23 D/A OUT 1
24 GND
25 CTR
26 GND
27 GND
28 PC +5 V
29 PC +5 V
30 TST
37 D-type, shielded
C37FF-x
C37FFS-x
C37FM-x
CIO-MINI37
SSR-RACK24
SSR-RACK08
CIO-ERB24
CIO-ERB08
6-7
Specifications
