miniLAB 1008 User's Guide

Testing the analog functions

InstaCal provides two tests that verify that the miniLAB 1008's analog functions are
working properly—a loop back test and a scan test.
The loop back test is a non-paced analog input test that verifies that a single analog
input is functional.
The scan test is a paced analog input test verifies that multiple analog inputs and the
pacer circuit are functional.
To access these tests, do the following:
1. From InstaCal's main form, pull down the
The
Board Test
the
Scan Test
2. Click on the tab of the test you want to perform and follow the procedures listed
below.
dialog opens with two tabs – the
tab. The dialog is shown configured with its default settings.
5-6
Calibrating and Testing the Device
menu and select
Test
Analog Loop Back Test
Analog.
tab and
