miniLAB 1008 User's Guide
Element
0
1
2
3
When a scan begins with the gain queue enabled, the miniLAB 1008 reads the first
element, sets the appropriate channel number and range, and then acquires a sample. The
properties of the next element are then retrieved, and another sample is acquired. This
sequence continues until all elements in the gain queue have been selected. When the
end of the channel list is detected, the sequence returns to the first element in the list.
This sequence repeats until the specified number of samples is gathered. You must
carefully match the gain to the expected voltage range on the associated channel—
otherwise, an over range condition can occur. Although this condition does not damage
the miniLAB 1008, it does produce a useless full-scale reading. It can also introduce a
long recovery time from saturation, which can affect the next measurement in the queue.

Digital connector cabling

Table 4-5 lists the digital I/O connector, applicable cables and accessory equipment. The
x in the compatible cable name indicates the length of the cable.
Connector type
Compatible cables
Compatible accessory products
Table 4-4. Sample channel gain queue list
Channel
CH0
CH0
CH7
CH2
Table 4-5. Digital connector and accessory equipment
Range
BIP10V
BIP5V
BIP10V
BIP1V
37 D-Type, shielded
C37FF-x (Figure 4-13)
C37FFS- x (Figure 4-14)
C37FM- x (Figure 4-15)
CIO-MINI37
SSR-RACK24
SSR-RACK08
CIO-ERB24
CIO-ERB08
4-16
Functional Details
