8. Error codes for Indoor and Outdoor Units

This list contains all possible values shown in Modbus register for "Error Code" for each indoor unit and outdoor
unit.
It must be taken into account that Outdoor Units are only able to reflect a single error for each indoor / outdoor unit
in the system. Thus, a unit having two or more active errors from that list will only report a single error code – the
one of the first error that has been detected.
Error Error in
Code Control Panel
0 N/A
1 A01
2 A02
3 A03
4 A04
5 A05
6 A06
7 A07
8 A08
9 A09
10 A10
11 A11
12 A12
13 A13
14 A14
15 A15
16 A16
17 A17
19 A19
20 A20
21 A21
22 A22
23 A23
24 A24
25 A25
26 A26
27 A27
28 A28
29 A29
30 A30
33 C01
34 C02
35 C03
36 C04
37 C05
38 C06
44 C12
48 C16
49 C17
50 C18
51 C19
52 C20
53 C21
54 C22
55 C23
© HMS Industrial Networks S.L.U. - All rights reserved
This information is subject to change without notice
Error category Error Description
N/A No active error
GHP - Engine oil pressure fault
GHP - Engine oil level fault
GHP - Engine over speed
GHP - Engine under speed
GHP - Ignition power supply failure
GHP - Engine start up failure
GHP - Fuel gas valve failure
GHP - Engine stalled
GHP - Engine overload
GHP - High exhaust gas temp
GHP - Engine oil level failure
GHP - Throttle actuator fault
GHP - Fuel gas valve adjustment failure
GHP - Engine oil pressure sensor fault
GHP Engine
GHP - Starter power output short circuit
Issues
GHP - Starter motor locked
GHP - Starter current (CT) coil failed
GHP - Wax Valve (3 Way) fault
GHP - Cooling water temp high
GHP - Cooling water level fault
GHP - Cooling water pump fault
GHP - Engine crank angle sensor failure
GHP - Engine cam angle sensor failure
GHP - Clutch fault
GHP - Misfire
GHP - Catalyst temperature fault
GHP - Generator fault
GHP - Converter fault
GHP - Fuel gas pressure low
Duplicated setting of control address
Central control number of units mis-matched
Incorrect wiring of central control
Incorrect connection of central control
System Controller fault, error in transmitting comms signal, i/door or
o/door unit not working, wiring fault
System Controller fault, error in receiving comms signal, i/door or
o/door unit not working, wiring fault, CN1 not connected correctly
Central
Batch alarm by local controller
Controller Issues
Transmission error from adaptor to unit
Reception error to adaptor from unit
Duplicate central address in adaptor
Duplicate adaptor address
Mix of PAC & GHP type units on adaptor
Memory fault in adaptor
Incorrect address setting in adaptor
Host terminal software failure
