HMS Intesis INMBSPAN016O000 User Manual page 10

Modbus Server – Panasonic
TM
Intesis
Read
Modbus Address
/Write
First Address is 0
([OU] * 25) +
(([L] - 1) * 10000) +
7000) + 1
([OU] * 25) +
(([L] - 1) * 10000) +
7000) + 2
([OU] * 25) +
(([L] - 1) * 10000) +
7000) + 3
([OU] * 25) +
(([L] - 1) * 10000) +
7000) + 4
([OU] * 25) +
(([L] - 1) * 10000) +
7000) + 5
([OU] * 25) +
(([L] - 1) * 10000) +
7000) + 6
2
([IU] * 100) +
3
(([L] - 1) * 10000) + 0
([IU] * 100) +
(([L] - 1) * 10000) + 1
([IU] * 100) +
(([L] - 1) * 10000) + 2
([IU] * 100) +
(([L] - 1) * 10000) + 3
([IU] * 100) +
(([L] - 1) * 10000) + 4
([IU] * 100) +
(([L]- 1) * 10000) + 5
([IU] * 100) +
W(T)
(([L]- 1) * 10000) + 6
([IU] * 100) +
(([L]- 1) * 10000) + 7
([IU] * 100) +
(([L]- 1) * 10000) + 8
([IU] * 100) +
(([L]- 1) * 10000) + 9
([IU] * 100) +
(([L]- 1) * 10000) + 10
([IU] * 100) +
(([L]- 1) * 10000) + 11
([IU] * 100) +
(([L]- 1) * 10000) + 12
([IU] * 100) +
(([L]- 1) * 10000) + 13
([IU] * 100) +
(([L]- 1) * 10000) + 14
([IU] * 100) +
(([L]- 1) * 10000) + 15
([IU] * 100) +
(([L]- 1) * 10000) + 16
([IU] * 100) +
(([L]- 1) * 10000) + 17
([IU] * 100) +
(([L]- 1) * 10000) + 18
([IU] * 100) +
(([L]- 1) * 10000) + 19
2 Where [IU] is the indoor unit number. Values from 1 to 64.
3
Where [L] is the Panasonic line in use. Posible values are 1 or 2.
© HMS Industrial Networks S.L.U. - All rights reserved
This information is subject to change without notice
Register/signal name
R/W
Demand Limit. Ratio
R
High Pressure Sensor (x10)
R
Low Pressure Sensor (x10)
R
Compressor 1 Operation Time
R
Compressor 2 Operation Time
R
Compressor 3 Operation Time
INDOOR UNITS SIGNALS
R/W
On/Off
R/W
Operation Mode
R/W
Fan Speed
R/W
Vane Position
R/W
Temperature Setpoint (x10ºC)
R
Ambient Temperature (x10ºC)
Wired Remote Controller
R/W
Discharge Setpoint Temperature Cool (x10ºC)
R/W
Discharge Setpoint Temperature Heat (x10ºC)
R
Discharge Current Temperature (x10ºC)
R
Heat Exchanger Temperature (x10)
R
Heat Setpoint Up Limit (x10)
R
Heat Setpoint Low Limit (x10)
R
Cool Setpoint Up Limit (x10)
R
Cool Setpoint Low Limit (x10)
R
Dry Setpoint Up Limit (x10)
R
Dry Setpoint Low Limit (x10)
R
Auto Setpoint Up Limit (x10)
R
Auto Setpoint Low Limit (x10)
R
Unit error code
User Manual r1.1 EN
Possible values
0..200 % - 255-No limit
Bar
Bar
0...16777215 hours
0...16777215 hours
0...16777215 hours
0-Off, 1-On
0-Auto, 1-Heat, 2-Dry. 3-Fan, 4-Cool, 5-
AutoHeat, 6-AutoCool
0-Auto, 1-Low, 2-Low+, 3-Med, 4-Med+,
5-High
0-Stop, 1-Pos1...5-Pos5, 10-Swing
16...30°C
-35...92,5ºC
-31...198,5ºF
0-Body sensor,
1-Remote controller sensor
-10...10ºC
13...50ºF
-10...10ºC
13...50ºF
-35...92,5ºC
-31...198,5ºF
-1...26ºC
30...79ºF
-35...92,5ºC
-31...198,5ºF
-35...92,5ºC
-31...198,5ºF
-35...92,5ºC
-31...198,5ºF
-35...92,5ºC
-31...198,5ºF
-35...92,5ºC
-31...198,5ºF
-35...92,5ºC
-31...198,5ºF
-35...92,5ºC
-31...198,5ºF
-35...92,5ºC
-31...198,5ºF
0-No error, X-Error (0...255)
