2.2.2 Subnetworking

A subnetwork (or subnet) is a logically visible subdivision of an IP (Internet
Protocol) network. Splitting an IP network into multiple subnets is referred to as
subnetting. Subnetting sets the region of the IP address that will be used as a
Network Prefix for all IP addresses inside of a subnet. This is accomplished
through a subnet mask. Different types of subnet masks and their implications to
IP addresses are shown in
Table 2-1 Subnetting
IP address
Subnet mask
Network prefix
Host Protocol
As seen in
are used as the network prefix.
In order for two network devices to communicate, they must be on the same
subnet. This means that they must not only be connected to the same internet
network, but must also have the same network prefix. If two devices have two
different network prefixes, this means that the two devices are on different subnets.

2.3 Transpector XPR 3+ IP Address

By default, Transpector XPR 3+ ships with an IP address of 192.168.1.100 with a
subnet mask of 255.255.0.0.
NOTE: When connecting Transpector XPR 3+ to an existing local network, there

2.3.1 Changing Transpector XPR 3+ IP Address

There are two different methods of changing the Transpector XPR 3+ IP address.
The first method utilizes the onboard Transpector Web UI to change the
IP address. Instructions for changing the IP address via Transpector Web UI can
be found in
Alternatively, the IP address can be changed through a standalone executable as
discussed next in
Table
Example 1
192.168.1.104
255.255.255.0
192.168.1.0
0.0.0.104
Table 2-1, the subnet masks determine which octets of the IP address
must be a static IP address for each Transpector XPR 3+ being installed.
Contact the network administrator for IP address assignments.
section 2.3.1.1.1 on page
section 2.3.1.1 on page
Transpector XPR 3+ Operating Manual
2-1.
Example 2 Example 3
192.168.1.105 192.168.1.150
255.255.0.0 255.255.255.192
192.168.0.0 192.168.1.128
0.0.1.105 0.0.0.22
2-5.
2-4.
2 - 3
