1.17.1 Two Digital Inputs

Logic Inputs 1 and 2 are by default set to remotely control emission status.
Connecting Pin 14 (Logic Input 1) to Pin 15 (Ground) will turn on the emission.
Connecting Pin 13 (Logic Input 2) to Pin 15 will turn off the emission. See
Table 1-2 Digital inputs
Emission ON
Emission OFF
GND

1.17.2 One Status Relay Output

One status relay output is active (closed) when the emission is on.
See Table
Table 1-3 Status relay output
EMISSION ON
EMISSION OFF
CONTACT RATING
1 - 26
PIN 14
PIN 13
PIN 15
CAUTION
Controlling emission through the digital inputs bypasses
all software or hardware interlocks. When using digital
inputs for controlling Transpector XPR 3+ emission,
develop an interlock that will not allow the emission to
turn on if the pressure is too high for operation of
Transpector XPR 3+.
1-3.
Relay closed. PIN 2 and PIN 1connected
Relay open
24 V(dc) at 0.5 A
