Alinx ZYNQ7000 FPGA User Manual page 22

Figure 6-4: 50Mhz active crystal oscillator on the AX7350B
PL Clock pin assignment:
DDR Reference Clock
A 200MHz differential crystal oscillator is provided to bank34 as the
reference clock of the DDR controller of PL;
Figure 6-3 200Mhz active crystal oscillator for DDR
22 / 46
ZYNQ FPGA Development Board AX7350B User Manual
Signal Name
CLK_50MHZ
Amazon Store: https://www.amazon.com/alinx
board
ZYNQ Pin
J14
