Ordering Information; Bill Of Materials - Analog Devices EVAL-ADIN1110EBZ User Manual

Preliminary UG-XXXX

ORDERING INFORMATION

BILL OF MATERIALS

Table 6.
Qty Reference Designator
14 AVDD_H, AVDD_L,
DVDD_1P1, GND1-6, INT_N,
LINK_ST, TS_CAPT, TS_TIMER,
VDDIO
6 C1, C2, C85, C86, C87, C88
2 C9, C10
2 C102, C103
2 C106, C107
1 C11
1 C13
2 C8, C15
3 C16, C19, C20
1 C18
2 C21, C23
19 C22, C24, C25, C27, C28, C29,
C30, C36, C38, C39, C41, C42,
C43, C61, C65, C66, C67, C72,
C76
2 C26, C31
2 C32, C34
2 C33, C35
2 C37, C40
4 C44, C46, C48, C75
2 C45, C47
6 C53, C63, C68, C69, C70, C74
1 C55
2 C77, C81
1 C82
2 C83, C84
1 D1
1 D123
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Description
Black test-point
Ceramic Capacitors, 0.001uF, 3000V,
10%, 1812, X7R
Ceramic Capacitors, 10uF, 50V, 10%,
1210, X7R
Ceramic Capacitors, 0.22uF, 100V, 10%,
1206, X7R
Ceramic Capacitors, 100pF, 3000V, 5%,
1812, COG
Ceramic Capacitor, 1UF, 6.3V, 10%, 0402,
X7R
Ceramic Capacitor, 6.8pF, 50V, 0.25pF
tol, 0402, NPO (COG)
Ceramic Capacitors, 0.1uF, 50V, 10%,
0603, X7R
Ceramic Capacitors, 10uF, 6.3V, 10%,
0805, X7R
Ceramic Capacitor, 10pF, 50V, 0.5pF tol,
0603, COG
Ceramic Capacitors, 1000pF, 50V, 5%,
0402, NPO (COG)
Ceramic Capacitors, 0.1uF, 25V, 10%,
0402, X7R
Ceramic Capacitors, 4.7uF, 6.3V, 20%,
0402, X5R
Ceramic Capacitors, 8pF, 16V, 0.5pF tol,
0402, COG
Ceramic Capacitors, 18pF, 50V, 5%,
0402, NPO (COG)
Ceramic Capacitors, 0.47uF, 16V, 10%,
0603, X7R
Ceramic Capacitors, 4.7uF, 16V, 10%,
0603, X5R
Ceramic Capacitors, 10pF, 50V, 5%,
0603, COG/NPO, High Temp
Ceramic Capacitors, 0.01uF, 25V, 10%,
0402, X7R
Ceramic Capacitor, 1000pF, 100V, 5%,
0603, COG
Ceramic Capacitors, 1uF, 16V, 10%,
0603, X7R
Ceramic Capacitor, 0.68uF, 10V, 10%,
0603, X7R
Ceramic Capacitors, 15pF, 50V, 1%,
0402, COG
Bidirectional TVS Diode
Bidirectional TVS diode surge/ESD
Rev. PrA | Page 20 of 23
EVAL-ADIN1110EBZ User Guide
Manufacturer Part Number
KEYSTONE CNKEY5005-9TP
ELECTRONICS
KEMET C1812C102KHRACTU
MURATA GRM32ER71H106KA12L
AVX 12061C224KAZ2A
KEMET C1812C101JHGACTU
MURATA GRM155R70J105KA12D
MURATA GJM1555C1H6R8CB01D
AVX 06035C104KAT2A
MURATA GCM21BR70J106KE22L
TDK C1608C0G1H100D080DA
MURATA GRM1555C1H102JA01
AVX CORPORATION 04023C104KAT2A
MURATA GRM155R60J475ME87D
AVX CORPORATION 0402YA8R0DAT2A
MURATA GJM1555C1H180JB01D
MURATA GCM188R71C474KA55D
TDK C1608X5R1C475K080AC
KEMET C0603H100J5GAC7867
TDK C1005X7R1E103K050EB
TDK C1608C0G2A102J
AVX 0603YC105KAT2A
YAGEO CC0603KRX7R6BB684
MURATA GCM1555C1H150FA16D
FAIRCHILD SMBJ36CA
SEMICONDUCTOR
BOURNS CDSOD323-T36SC
