TROUBLESHOOTING

SOFTWARE INSTALLATION TIPS

Ethernet PHY software installation tips follow:
•
Always allow the software installation to be completed.
The FTDI drivers can be found at
www.ftdichip.com/Drivers/CDM/CDM21228_Setup.zip.
The installation may require a restart of the PC.
•
If the EVAL-ADIN1110EBZ does not appear in the UART
terminal window, ensure that the following steps have
been competed:
- Power is applied to the EVAL-ADIN1110EBZ.
- The powered USB connector is connected to the
EVAL-ADIN1110EBZ.
- The Ethernet cable is connected between the two
boards (if using two boards).
- The correct COM port is configured.
- Try perform a hardware reset, using the S5 push-
button switch.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
EVAL-ADIN1110EBZ User Guide

HARDWARE TIPS

Ensure that power is applied to the EVAL-ADIN1110EBZ.
Measure the voltage at various points on the EVAL-
ADIN1110EBZ using the 3V3, 1V8, 1V1, AVDD_H, AVDD_L,
VDDIO and DVDD_1P1 test points.
No Link Established
If no link is established, take the following steps to assist debug:
•
Ensure that the Ethernet cable is connected properly to the
P101 connector and between the EVAL-ADIN1110EBZ
boards or MAC-PHY pairs.
•
When using two EVAL-ADIN1110EBZ boards, ensure
that both boards are powered.
•
Ensure that the hardware configuration is appropriate for
the required linking arrangement.
Rev. PrA | Page 10 of 23
