Preliminary UG-XXXX
Qty Reference Designator
1 R47
2 R48, R70
1 R5
10 R50, R60, R61, R62, R63, R64,
R72, R87, R88, R91
1 R53
1 R54
2 R66, R67
1 R7
4 R74, R78, R79, R80
1 R9
2 S1, S4
2 S3, S5
1 U1
1 U2
1 U3
1 U4
1 U5
1 U6
1 U7
1 U8
1 U9
1 Y1
1 Y2
1 Y3
Table 7. Not Populated
Qty Reference Designator
8 1V1, 1V8, 3V3, CLK25_REF,
MDC, MDIO, P16, P18
2 C17, C101
6 C14, C49, C64, C78, C79, C80
3 C5, C6, C7
2 C89, C90
1 J1
3 J111, P19,P20
1 L3
1 P9
2 R113, R114
2 R13, R86
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Description
Resistor, 470 kOhm, 1%, 0402
Resistor, 100 kOhm, 50 V, 1%, 0603
Resistor, 392 kOhm, 1%, 0402
Resistors, 0 Ohm, 5%, 0603
Resistor, 0 Ohm, 1%, 0402
Resistor, 0 Ohm, 1%, 0603
Resistors, 1.5 kOhm, 50 V, 1%, 0603
Resistor, 1 kOhm, 1%, 0402
Resistors, 4.7 kOhm, 1%, 0603
Resistor, 121 kOhm, 1%, 0402
4-position surface mount switch
Ultra small push-button switch
4-line ESD protection for high speed
lines
LT8619 60V, 1.2A Synchronous
monolithic buck regulator
USB Serial UART
ADuCM4050 ultra low power ARM
cortex microcontroller
LTC3547 Dual monolithis synchronous
step-down regulator
Ultra low power, 64MBit CMOS MXSMIO
Flash Memory
2-input AND gate
ADIN1110 Robust industrial low power
10BASE-T1L ethernet MAC-PHY
CMOS inverter
32.768 kHz crystal
26 MHz crystal
25 MHz crystal
Description
Test-points
Ceramic Capacitors, 4.7 pF, 100 V, 0.1pF
tol, 0603, COG
Ceramic Capacitors, 0.1 uF, 25 V, 10%,
0402, X7R
Ceramic Capacitors, 10 uF, 50 V, 10%,
1210, X7R
Ceramic Capacitors, 0.022 uF, 100 V,
10%, 0805, X7R
SMA
2-way PCB link
22 uH common mode line filter, 2.65
Ohm
4-way header
Resistors, 1.5 kOhm, 1%, 0805
Resistors, 0 Ohm, 5%, 0603
Rev. PrA | Page 22 of 23
EVAL-ADIN1110EBZ User Guide
Manufacturer Part Number
PANASONIC ERJ-2RKF4703X
PANASONIC ERJ-3EKF1003V
YAGEO RC0402FR-07392KL
PANASONIC ERJ-3GEY0R00V
MULTICOMP (SPC) MC00625W040210R
MULTICOMP (SPC) MC0603WG00000T5E-TC
MULTICOMP (SPC) MC 0.063W 0603 1% 1K5
PANASONIC ERJ-2RKF1001X
MULTICOMP (SPC) MC 0.063W 0603 1% 4K7.
PANASONIC ERJ-2RKF1213X
CTS 219-4MST
OMRON B3U-1000P
ST HSP051-4M10
MICROELECTRONICS
LINEAR LT8619EDD#PBF
TECHNOLOGY
FTDI CHIP FT232RQ
ANALOG DEVICES ADUCM4050BCPZ
ANALOG DEVICES LTC3547BIDDB#TRMPBF
MACRONIX MX25R6435FM2IL0
NEXPERIA 74LVC1G08GV,125
ANALOG DEVICES ADIN1110CCPZ
FAIRCHILD NC7S04M5X
SEMICONDUCTOR
ABRACON CORP. ABS07-120-32.768KHZ-T
ECS, INC. ECS-260-10-36Q-ES-TR
SEIKO EPSON FA-
128_25.000000MHZ_10.0
_+10-10
Supplier Part Number
KEYSTONE 1405-2
ELECTRONICS
MURATA GCM1885C2A4R7BA16D
AVX CORPORATION 04023C104KAT2A
MURATA GRM32ER71H106KA12L
AVX 08051C223KAT2A
TE CONNECTIVITY 5-1814832-2
LTD
AMPHENOL FCI 69157-102HLF
WURTH ELEKTRONIK 744235220
SAMTEC TSW-104-08-G-S
PANASONIC ERJ-6ENF1501V
PANASONIC ERJ-3GEY0R00V
