Command Line Interface
Diagnostics and Identification Commands
Parameter Name
SW
BL
BT
The INFO command without Parameter Name indicates all values:
HPT404BT GSM High Power UHF Transceiver, Javad GNSS
Product ID =47
S/N =000000000024
Hardware =Ver. 2.2
Software =Ver. 1.8 Rev 05 B85
BootLoader =Ver. 3.0 Rev 05
BT addr =00:18:D7:00:3D:03

5.2. STATE

The STATE command is used to check the state of the wireless link and the alarm control lines.
STATE [Parameter Name] [Parameters List] [/?]
Parameter
Name
RSSI
BER
FREQ
FREQTX
TEMP
SYNC
MODE
VHPA
BT
The STATE command without Parameter Name indicates all values as shown below:
RSSI =-147 dBm
BER =0E-0
FREQ =431.000000 MHz
FREQTX =431.000000 MHz
CHAN =-4
38
Ver. 1.0 Rev. A - displays software's version in numeric "Major.Minor" format and
revision in numeric format (range from 01 to 99) for engineering releases and alphabetic
format (A to Z) for manufacturing releases
Ver. 1.0 Rev. A - displays BootLoader's version in numeric "Major.Minor" format and
revision in numeric format (range from 01 to 99) for engineering releases and alphabetic
format (A to Z) for manufacturing releases
Bluetooth serial number
-15 to -137 dBm - Indicates the Receive Signal Strength in dBm
0 to 9.9E-3 - Indicates the BER level
406.000000 to 470.000000 MHz - Displays the central frequency of the operating
channel
406.000000 to 470.000000 MHz - Displays the central frequency of the operating
channel
-30.C to 100.C. Displays the temperate inside of enclosure.
0 - if link is not established yet
1 - indicates the link established
AUTO/FHOP/FIXED
VCC V
ON/OFF
Parameter List
Parameter List
