Number
3
4
5
6
7
8
9
10
11
12
13
14
15
External Antenna RF Connector
The external antenna connector type is a BNC RF connector AEP Connectors 6501-7051-003.
GSM Antenna Connector
GSM Antenna Connector is a standard SMA connector.
www.javad.com
Signal Name Dir
RX+/CTS_IN I
RX-/RX_IN I
PWR_IN I
USB_PWR I
Ground -
PWR_IN I
DSR_IN I
TX+/RTS_OUT O
TX-/TX_OUT O
Ground -
USB_D+ I/O
USB_D- I/O
Ground -
Receive Data positive line (RS-422/RS485)/Clear to Send (RS-232)
Receive Data negative line (RS-422/RS485)/Receive Data (RS-232)
+9 to +36 VDC Power Input
Power Input line (USB)
Power Ground
+9 to +36 VDC Power Input
Data Set Ready (RS-232)
Transmit Data positive line (RS-422/RS485) /Request to Send (RS-232)
Transmit Data negative line (RS-422/RS485) / Transmit Data (RS-232)
Power Ground
Positive line (USB)
Negative line (USB)
Power Ground
Connector Specifications
Details
Specifications
