07 VIDEO SUPPORT RESOLUTION

[1] SDI MODE
Input Signal
Interface
SD SDI
Single Link
Input Signal
Interface
HD SDI
Single Link
Input Signal
Interface
3G-SDI (A/B)
Single Link
[2] HDMI MODE
Input Signal
Interface
HDMI
720x487(59.94i)
720x576(50i)
1920x1080(23.98/24/25/29.97/30p)
(50/59.94/60i) (24/25/29.97/30psf)
1280x720(50/59.94/60P)
1920x1080(60p/59.94p/50p)
1920x1080(30/29.97/25/24/23.98/
30sF/29.97sF/25sF/24sF/23.98sF)
1080p(60/59.94/50/30/29.97/25/24/23.98)
1080i(60/59.94/50)
720p(50/59.94/60p)
480i(60) / 576i(50)
480p(60) / 576p(50)
Signal Format (SD SDI)
YCbCr 4:2:2 10bit
Signal Format (HD SDI)
YCbCr 4:2:2 10bit
Signal Format (3G SDI)
YCbCr 4:2:2 10bit
RGB 4:4:4 10bit / 12bit
YCbCr 4:4:4 10bit / 12bit
Signal Format (HDMI)
RGB 4:4:4 8bit / 10bit / 12bit
YCbCr 4:4:4 8bit / 10bit / 12bit
YCbCr 4:2:2 8bit / 10bit / 12bit
