Alinx AX301 User Manual page 25

Fpga development board
Hide thumbs Also See for AX301:
Table of Contents

Advertisement

Figure 11-2: SD card slot on the FPGA Board
SD card slot pin assignment
Pin Name
SD_NCS
SD_DIN
SD_CLK
SD_DOUT
25 / 36
FPGA Development Board AX301 User Manual
Figure 11-1: SD card slot schematic
SD Mode
Amazon Store: https://www.amazon.com/alinx
FPGA Pin
D11
F10
D12
E15
