continuous time information. Figure 8-1 shows the design of the DS1302:
Figure 8-1: DS1302 schematic
Figure 8-12: DS1302 on the FPGA Board
DS1302 interface pin assignment:
Pin Name FPGA Pin
P6
RTC_SClK
N8
RTC_nRST
M8
RTC_DATA

Part 9: USB to Serial Port

The development board contains the Silicon Labs CP2102GM USB-UAR
