SDRAM pin assignment:
Pin Name
S_CLK
S_CKE
S_NCS
S_NWE
S_NCAS
S_NRAS
S_DQM<0>
S_DQM<1>
S_BA<0>
S_BA<1>
S_A<0>
S_A<1>
S_A<2>
S_A<3>
S_A<4>
S_A<5>
S_A<6>
S_A<7>
S_A<8>
S_A<9>
S_A<10>
S_A<11>
S_A<12>
S_DB<0>
S_DB<1>
S_DB<2>
S_DB<3>
S_DB<4>
S_DB<5>
S_DB<6>
S_DB<7>
S_DB<8>
16 / 36
FPGA Development Board AX301 User Manual
Amazon Store: https://www.amazon.com/alinx
FPGA Pin
B14
F16
K10
J13
J12
K11
J14
G15
G11
F13
F11
E11
D14
C14
A14
A15
B16
C15
C16
D15
F14
D16
F15
P14
M12
N14
L12
L13
L14
L11
K12
G16
