CON1 Pin
Signal Name
1
+5V
3
+5V
5
+5V
7
+5V
9
GND
11
PS_MIO13
13
PS_MIO12
15
-
17
-
19
GND
21
-
23
-
25
-
27
-
29
GND
31
PS_MIO7
33
PS_MIO8
35
PS_MIO9
37
PS_MIO11
39
GND
41
-
43
-
45
-
47
-
49
GND
51
XADC_VP
53
XADC_VN
55
-
57
PS_MIO10
59
GND
61
SD_CLK
25 / 30
ZYNQ FPGA Development Board AC7021B User Manual
ZYNQ Pin
-
-
-
-
-
A6
C5
-
-
-
-
-
-
-
-
D5
E5
C4
B4
-
-
-
-
-
-
L11
M12
-
G7
-
E14
Amazon Store: https://www.amazon.com/alinx
CON1 Pin
Signal Name
2
+5V
4
+5V
6
+5V
8
+5V
10
GND
12
ETH_TXD0
14
ETH_TXD1
16
ETH_TXD2
18
ETH_TXD3
20
GND
22
ETH_TXCK
24
ETH_TXCTL
26
ETH_RXD3
28
ETH_RXD2
30
GND
32
ETH_RXD1
34
ETH_RXD0
36
ETH_RXCTL
38
ETH_RXCK
40
GND
42
ETH_MDC
44
ETH_MDIO
46
OTG_STP
48
OTG_DIR
50
GND
52
OTG_CLK
54
OTG_NXT
56
OTG_DATA0
58
OTG_DATA1
60
GND
62
OTG_DATA2
ZYNQ Pin
-
-
-
-
-
E9
A7
E10
A8
-
D6
F11
A13
F12
-
B7
E11
D7
A14
-
D10
C12
A11
E8
-
A9
F9
C7
G13
-
B12
