Introduction, cont'd
The 2U frame has four single board slots, the 3U frame has six single board slots,
the 4U frame has eight slots, and the 5U has ten slots. Each slot supports power
and control connections to the I/O boards. When a board is installed into a slot it
may use more than one slot. For example the SMX 1616 VGA board uses four slots.
The slots a board covers are not available for other I/O board installation until that
(multi-slot) board has been removed. See

Definitions

The following terms are used throughout this manual:
Tie — An input-to-output connection.
Set of ties — An input tied to two or more outputs. An output can never be tied to
Configuration — One or more ties or one or more sets of ties.
Current configuration — The configuration that is currently active in the switcher
Global memory preset — An I/O configuration that has been stored (all planes).
Plane memory preset — A plane configuration that has been stored. Up to 10
EDID — Extended Display Identification Data. A communications protocol or
HDCP — High-bandwidth Digital Content Protection. An encryption method
DVI — Digital Visual Interface. The digital video connectivity standard that
HDMI — High Definition Multimedia Interface. A specification developed by
SDI — Serial Digital Interface. The standard based on a 270 Mbps transfer rate.
HD-SDI — High-definition version of SDI specified in SMPTE-292M. This
1-4 SMX System MultiMatrix Switchers • Introduction
more than one input.
(also called configuration 0).
Up to 32 global memory presets can be stored. Preset locations are assigned
to the input buttons and output buttons and can be selected from the front
panel, by serial port, or Ethernet control, for either saving or retrieving.
When a preset is recalled from memory, it becomes the current configuration.
plane presets per switching plane can be saved and recalled without affecting
the other I/O plane connections. A plane is all the inputs and outputs of one
signal type.
instruction set developed by VESA (Video Electronics Standards Association)
for the identification of display devices to computers using the DDC (Display
Data Channel) transmission standard.
developed by Intel that protects copyrighted digital entertainment material
that uses the Digital Video Interface (DVI) and High Definition Multimedia
Interface (HDMI).
was developed by DDWG (Digital Display Work Group). This connection
standard offers two different connectors: one with 24 pins that handles digital
video signals only, and one with 29 pins that handles both digital and analog
video. This standard uses TDMS (Transition Minimized Differential Signal)
from Silicon Image and DDC (Display Data Channel) from VESA (Video
Electronics Standards Association). DVI-D supports digital signal transfer
only, and DVI-I supports both digital and analog signal transfer.
the HDMI Working Group that combines video, multi-channel audio, and
control signals into a single digital interface for use with DVD players, digital
television, and other audiovisual devices.
This is a 10-bit, scrambled, polarity independent interface with common
scrambling for both component ITU-R 601 and composite digital video and
four channels of (embedded) digital audio.
standard transmits audio and video over a single coaxial cable with a data
rate of 1.485 Gbit/second.
Chapter 2 for details.
