13.8 Fresh gas flow

Fresh gas flow
Gas mix:
Air/O
2
O /N O
2 2
Fresh gas flow range
Fresh gas O /air Flow
2
(numerical/bargraph)
Fresh gas O /N O Flow
2 2
(numerical/bargraph)
Preset O concentration
2
Setting resolution
O Flush
2

13.9 Anesthesia gas scavenging (AGS)

Anesthesia gas scavenging (AGS)
Type
Scavenging flow
Outlet connection type options
FLOW-i 4.2, User's Manual
Electronic Servo controlled
Electronic Servo controlled
• MAN = 0.3 - 20 l/min
• AUTO = 0.3 - 20 l/min (FGF delivery depending on set MV)
• AFGO = 1.0 - 20 l/min
Selectable
Selectable
Air/O
2
O /N O
2 2
1%
• Approximately 55 l/min
• 2 cmH O expiratory resistance when APL is set to SP
2
Passive system (including a flow indicator) integrated into the system
Minimum 25 l/min (STPD), or 10 l/min (STPD) over the set minute
volume, whichever is greater.
• 30 mm ISO taper
• DISS EVAC
• 12.7 mm / ½" in hose Barb
• 25 mm / 1" Barb
• AGA EVAC
• WAGD-to-Vacuum connector
• 22 mm out. diam. connector and 22 mm int. diam. connection
tube
| Technical specifications
21% - 100% ±5%
28% – 100% ±5%
| 13 |
