AFGO (Additional Fresh Gas Outlet, Option)

7.1 General

Additional Fresh Gas Outlet (AFGO) is an
option to the anesthesia system that allows
use of an external partial rebreathing system,
such as Bains, Jackson Rees or Mapleson D.
When using AFGO the circle system is
bypassed and the following can be set:
Gas mix
O
concentration
2
Fresh gas flow
Agent concentration
Fresh gas flow ranges are from 1.0 to 20 l/min
when using the AFGO and the default settings
are the same as in Manual ventilation.
1. Air gas module
2. O
gas module
2
3. N
O gas module
2
4. Vaporizer
150
1
2
3
4
|
Pre-selecting or activating AFGO in the
ventilation dialog window requires user
confirmation. On selecting the AFGO
touchpad, a pop-up dialog appears asking the
user to confirm the action.
When the MAN/AUTO switch is set to AUTO
it is possible to preset MAN mode to AFGO in
the ventilation dialog window. AFGO is
activated when the MAN/AUTO switch is then
turned to MAN.
When the MAN/AUTO switch is set to MAN it
is possible to activate AFGO in the ventilation
dialog window.
